7808 20 11 by Parker | Pneumatic Threshold Sensor | 1/8" Male NPT Thread x 1/8" Female NPT Thread | 9/16" Hex | 1.89" Length | Straight | Nylon

7808 20 11 by Parker | Pneumatic Threshold Sensor | 1/8" Male NPT Thread x 1/8" Female NPT Thread | 9/16" Hex | 1.89" Length | Straight | Nylon

Save $4.45 Save $4.45
$61.16
$61.16 - $61.16
$61.16
$56.71
$56.71 - $56.71
$56.71

by Parker Hannifin
Threshold Sensor Fittings:7808 - pneumatic threshold sensor 10-32 UNF pilot/signal ports to NPT
Specifications for Variant SKU: 7808 20 11 Parker
Series: 7808 Series
Shape (Orientation): Straight
Material(s): Brass, Glass-Reinforced Nylon
Seal Material(s): Buna-N/Nitrile Rubber
Special Properties: Valved
Product Features:
  • Glass-reinforced nylon 6.6 body
  • Brass screw
  • NBR seal
  • Silicone-Free
Markets:
  • Factory/Process Automation
  • Packaging
  • Pneumatics
  • Semi-Conductor
Applications:
  • Robotics
  • Packaging
  • Textile
  • Machine Tools
  • Pneumatic Systems
Pressure Range
  • 43.5 to 116 psi (3 to 8 bar)
Temperature Range
  • 5° to 140° F (-15° to 60° C)
Back Pressure
  • 08.5 psi to 1 bar
Response Time
  • 3 ms
Compatible Tubing:
  • Semi-Rigid Nylon
  • Polyurethane 95 Durometer Shore A
  • Fluoropolymer
Part Number NPT (C) orifice F H J L Oz
7808 20 11 1/8" .20 9/16" .90" .62" 1.58" 1.66 Oz
7808 20 18 3/8" .39 7/8" 1.13" .92" 1.76" 3.46 Oz
Parker Fluid System Connectors Division

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
