9123 23 10 by Parker | Legris Coupler Quick Disconnect | 10 mm Hose Barb | 19 mm Hex | 74 mm Length | Straight | Nickel-Plated Brass | Pack of 5

Save $134.05

$335.12

$335.12 - $335.12

$335.12

$201.07

$201.07 - $201.07

$201.07

by Parker Hannifin
Series 23 - Brass/Steel:9123 Coupler with valve, Hose Barb

Package Quantity: 5 Units

Specifications for Variant SKU: 9123 23 10 Parker \| 5 \|
Series:	23 Series
Shape (Orientation):	Straight
Material(s):	Nickel-Plated Brass
Seal Material(s):	Buna-N/Nitrile Rubber

Series 23 - Brass/Steel Series: Single Shut-Off	1/4" industrial coupling with UltraFlo technology in accordance with ISO 6150 B and US Mil. SPEC 4109. Especially suitable for use with gaseous media in industry. Steel sleeve counters oscillating forces. Special variants with brass valve for use with liquids. High flow performance with low pressure drop and a multitude of connection options. Available on request: with additional end connections other seals for different temperature ranges and fluids
Working Pressure:	up to 35 bar
Material:	Coupling: Nickel-Plated Brass Plug: Nickel-Plated Steel / Brass Seals: NBR
Working Temperature:	-20°C up to +100°C (NBR)
Flow Rate Air:	960 l/min. (inlet pressure 6 bar, pressure dop 0.5 bar)
Flow Rate Water:	14 l/min. (pressure drop 0.5 bar)


Part Number	A	Hex	L	L1	D
9123 23 08	8 mm	19 mm	74 mm	25 mm	23 mm
9123 23 10	10 mm	19 mm	74 mm	25 mm	23 mm

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
