GRB300 by Kuriyama | Quick-Acting Coupling | Part B | 3" Female Coupler x 3" Male NPT | Nylon

GRB300 by Kuriyama | Quick-Acting Coupling | Part B | 3" Female Coupler x 3" Male NPT | Nylon

Save $9.00 Save $9.00
$31.51
$31.51 - $31.51
$31.51
$22.51
$22.51 - $22.51
$22.51

Kuriyama Couplings™ - Quick-Acting Couplings - Part B - Female Coupler x Male NPT - Nylon

Specifications for Variant SKU: GRB300 Kuriyama
Shape (Orientation): Straight
Cam Type: Type B
Ends Configuration: 3in Female Cam & Groove, 3in Male NPT
Material(s): Nylon, 304 Stainless Steel
Seal Material(s): EPDM
Applications:
  • Agriculture, Chemicals/Petroleum, Construction, Material Handling, Irrigation, Fracking
  • For use with Kuriyama Hoses
Features:
  • All sizes comply with Mil-Spec A-A-59326 for interchangeability.
  • Nylon material is fiberglass reinforced for high tensile strength and durability.
  • Locking feature using safety clips to prevent disconnection during use on all sizes.
  • All 4" size female couplers are supplied with three locking handles to provide added stability.
Materials:
  • Type 304 stainless steel handles.
  • Type 304 stainless steel handle pins.
  • Type 304 stainless steel pull rings.
  • Type 304 stainless steel safety clips.
  • EPDM gaskets.
Part Number Size Weight (Lbs.)
GRB100 1" x 1" 0.16 lbs.
GRB150 1-1/2" x 1-1/2" 0.46 lbs.
GRB200 2" x 2" 0.52 lbs.
GRB300 3" x 3" 1.02 lbs.
GRB400 4" x 4" 1.34 lbs.
Kuriyama

Kuriyama

Located in Schaumburg, Illinois, Kuriyama of America has been eminently successful in developing and marketing a complete line of thermoplastic hose and accessories. Their expansive product line consist of thermoplastic, rubber and metal hose products, along with accessories including couplings and fittings.
