HUT206-6 by Kuriyama | Figure 206 | Threaded Hammer Union | 2000 PSI | CWP | 6" Female NPT x 6" Female NPT | Buna-N

Save $59.12

$311.17

$311.17 - $311.17

$311.17

$252.05

$252.05 - $252.05

$252.05

Kuriyama Couplings™ - Hammer Unions - Figure 206 - Threaded Female NPT x Female NPT - 2000 PSI CWP

Quantity

Specifications for Variant SKU: HUT206-6 Kuriyama
Shape (Orientation):	Straight
Ends Configuration:	6in Female NPT, 6in Female NPT
Material(s):	Ductile Iron
Seal Material(s):	Buna-N/Nitrile Rubber

Applications:
Applications include oil, gas, air, and water. For use with Kuriyama Hoses
Features:
General Purpose Union With O-Ring in Male Sub for Improved Sealing Unions conform to NACE, ISO and DNV standards. Color coded for easy identification. CWP (Cold Working Pressure) is the maximum pressure at 70 deg. F (+21 deg. C). Unions are completely interchangeable with competitors of like products.
Materials:
ASTM Grade 65-45-12 ASTM A-105 ASTM A29 NPT threads conform to ASME B1.20.1 Elastomer seals are BUNA-N

Part Number	Size	Weight (Lbs.)
HUT206-2	2" x 2"	4.60 lbs
HUT206-3	3" x 3"	11.80 lbs
HUT206-4	4" x 4"	19.10 lbs
HUT206-6	6" x 6"	45.00 lbs
HUT206-8	8" x 8"	66.00 lbs

Kuriyama

Located in Schaumburg, Illinois, Kuriyama of America has been eminently successful in developing and marketing a complete line of thermoplastic hose and accessories. Their expansive product line consist of thermoplastic, rubber and metal hose products, along with accessories including couplings and fittings.
