DG063-3000-S-UNF by Brennan Inc. | Pressure Gauge | 0-3000 PSI | for 1/4" SAE Stem | Stainless Steel

DG063-3000-S-UNF by Brennan Inc. | Pressure Gauge | 0-3000 PSI | for 1/4" SAE Stem | Stainless Steel

$41.18 - $41.18
$41.18
$52.25
$52.25 - $52.25
$52.25

Brennan Inc.
Test Point Fittings: Pressure Gauge
Specifications for Variant SKU: DG063-3000-S-UNF Brennan
Material(s): Stainless Steel
Gauge Vesion Dimensions (in/mm)
A B C D E F G
Stem Mount 2.80" / 71mm 1.40" / 36mm 1.07" / 27mm 3.55" / 90mm 1/4" NPT - -
Panel Mount - U-Bolt 2.80" / 71mm 1.34" / 34mm 0.94" / 24mm 2.28" / 58mm 1/4" NPT 3.84" / 98mm 2.48" / 63mm
Panel Mount - Flange 2.80" / 71mm 1.34" / 34mm 0.94" / 24mm 2.28" / 58mm 1/4" NPT 3.45" / 88mm 2.48" / 63mm
Part Number Material Description PSI
DG063-100-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-100 PSI
DG063-100-S-NPT Stainless Steel for 1/4" NPT Stem 0-100 PSI
DG063-1000-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-1000 PSI
DG063-1000-S-NPT Stainless Steel for 1/4" NPT Stem 0-1000 PSI
DG063-1000-S-UNF Stainless Steel for 1/4" SAE Stem 0-1000 PSI
DG063-10000-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-10000 PSI
DG063-10000-S-NPT Stainless Steel for 1/4" NPT Stem 0-10000 PSI
DG063-10000-S-UNF Stainless Steel for 1/4" SAE Stem 0-10000 PSI
DG063-1500-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-1500 PSI
DG063-1500-S-NPT Stainless Steel for 1/4" NPT Stem 0-1500 PSI
DG063-2000-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-2000 PSI
DG063-2000-S-NPT Stainless Steel for 1/4" NPT Stem 0-2000 PSI
DG063-2000-S-UNF Stainless Steel for 1/4" SAE Stem 0-2000 PSI
DG063-300-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-300 PSI
DG063-300-S-NPT Stainless Steel for 1/4" NPT Stem 0-300 PSI
DG063-3000-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-3000 PSI
DG063-3000-S-NPT Stainless Steel for 1/4" NPT Stem 0-3000 PSI
DG063-3000-S-UNF Stainless Steel for 1/4" SAE Stem 0-3000 PSI
DG063-30HG15-PU-NPT Stainless Steel Panel Mount with U-Bracket 30"HG-15
DG063-30HG15-S-NPT Stainless Steel for 1/4" NPT Stem 30"HG-15
DG063-4000-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-4000 PSI
DG063-4000-S-NPT Stainless Steel for 1/4" NPT Stem 0-4000 PSI
DG063-5000-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-5000 PSI
DG063-5000-S-NPT Stainless Steel for 1/4" NPT Stem 0-5000 PSI
DG063-5000-S-UNF Stainless Steel for 1/4" SAE Stem 0-5000 PSI
DG063-600-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-600 PSI
DG063-600-S-NPT Stainless Steel for 1/4" NPT Stem 0-600 PSI
DG063-600-S-UNF Stainless Steel for 1/4" SAE Stem 0-600 PSI
Brennan

Brennan

Brennan Industries, founded in 1953, distinguishes itself with a commitment to quality in hydraulic and pneumatic fittings. With over 120,000 styles and sizes, Brennan serves a global market through extensive distribution networks. As a privately held company, Brennan's principals actively oversee operations, ensuring top-tier customer service and responsiveness. Their products meet or exceed J.I.C./S.A.E. and international standards, supported by ISO 9001:2015, AS9100D, and NADCAP certifications. Brennan's offerings include standard and custom solutions, backed by robust engineering support. With 13 distribution centers worldwide, Brennan delivers exceptional quality, service, and competitive pricing for all hydraulic and pneumatic fitting needs.
