DG063-10000-PU-NPT by Brennan Inc. | Pressure Gauge | 0-10000 PSI | Panel Mount with U-Bracket | Stainless Steel

DG063-10000-PU-NPT by Brennan Inc. | Pressure Gauge | 0-10000 PSI | Panel Mount with U-Bracket | Stainless Steel

Save $4.45 Save $4.45
$40.01
$40.01 - $40.01
$40.01
$35.56
$35.56 - $35.56
$35.56

Brennan Inc.
Test Point Fittings: Pressure Gauge
Can I get a discount on my purchase?

Our listed prices are our lowest possible price with current costing but when volumes/value are high enough sometimes we can pass on a discount from the manufacturer.

Some products have predefined quantity discounts that will apply automatically, those pages have a table near the price describing the discount teirs.

If you feel your purchase quantity of a particular product is very large and want us to investigate with the manufacturer please feel free to Contact Us.

What if my item is out of stock?

All customers get an email regarding the shipping time frame of their purchase, usually within the business day. If your item is in stock we will ship within 1 business day, otherwise, the email will contain a lead time. If you do not receive this email, we recommend checking your email's spam folder. If you have any questions at that point please do not hesitate to Contact Us or chat below!

Can I get free shipping?

Shipping will calculate as free instantly if your order value exceeds $5000.

Some exceptions apply.

Free Freight is only available for the Contiguous USA.

Specifications for Variant SKU: DG063-10000-PU-NPT Brennan
Material(s): Stainless Steel
Gauge Vesion Dimensions (in/mm)
A B C D E F G
Stem Mount 2.80" / 71mm 1.40" / 36mm 1.07" / 27mm 3.55" / 90mm 1/4" NPT - -
Panel Mount - U-Bolt 2.80" / 71mm 1.34" / 34mm 0.94" / 24mm 2.28" / 58mm 1/4" NPT 3.84" / 98mm 2.48" / 63mm
Panel Mount - Flange 2.80" / 71mm 1.34" / 34mm 0.94" / 24mm 2.28" / 58mm 1/4" NPT 3.45" / 88mm 2.48" / 63mm
Part Number Material Description PSI
DG063-100-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-100 PSI
DG063-100-S-NPT Stainless Steel for 1/4" NPT Stem 0-100 PSI
DG063-1000-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-1000 PSI
DG063-1000-S-NPT Stainless Steel for 1/4" NPT Stem 0-1000 PSI
DG063-1000-S-UNF Stainless Steel for 1/4" SAE Stem 0-1000 PSI
DG063-10000-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-10000 PSI
DG063-10000-S-NPT Stainless Steel for 1/4" NPT Stem 0-10000 PSI
DG063-10000-S-UNF Stainless Steel for 1/4" SAE Stem 0-10000 PSI
DG063-1500-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-1500 PSI
DG063-1500-S-NPT Stainless Steel for 1/4" NPT Stem 0-1500 PSI
DG063-2000-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-2000 PSI
DG063-2000-S-NPT Stainless Steel for 1/4" NPT Stem 0-2000 PSI
DG063-2000-S-UNF Stainless Steel for 1/4" SAE Stem 0-2000 PSI
DG063-300-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-300 PSI
DG063-300-S-NPT Stainless Steel for 1/4" NPT Stem 0-300 PSI
DG063-3000-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-3000 PSI
DG063-3000-S-NPT Stainless Steel for 1/4" NPT Stem 0-3000 PSI
DG063-3000-S-UNF Stainless Steel for 1/4" SAE Stem 0-3000 PSI
DG063-30HG15-PU-NPT Stainless Steel Panel Mount with U-Bracket 30"HG-15
DG063-30HG15-S-NPT Stainless Steel for 1/4" NPT Stem 30"HG-15
DG063-4000-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-4000 PSI
DG063-4000-S-NPT Stainless Steel for 1/4" NPT Stem 0-4000 PSI
DG063-5000-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-5000 PSI
DG063-5000-S-NPT Stainless Steel for 1/4" NPT Stem 0-5000 PSI
DG063-5000-S-UNF Stainless Steel for 1/4" SAE Stem 0-5000 PSI
DG063-600-PU-NPT Stainless Steel Panel Mount with U-Bracket 0-600 PSI
DG063-600-S-NPT Stainless Steel for 1/4" NPT Stem 0-600 PSI
DG063-600-S-UNF Stainless Steel for 1/4" SAE Stem 0-600 PSI
Brennan

Brennan

Brennan Industries, founded in 1953, distinguishes itself with a commitment to quality in hydraulic and pneumatic fittings. With over 120,000 styles and sizes, Brennan serves a global market through extensive distribution networks. As a privately held company, Brennan's principals actively oversee operations, ensuring top-tier customer service and responsiveness. Their products meet or exceed J.I.C./S.A.E. and international standards, supported by ISO 9001:2015, AS9100D, and NADCAP certifications. Brennan's offerings include standard and custom solutions, backed by robust engineering support. With 13 distribution centers worldwide, Brennan delivers exceptional quality, service, and competitive pricing for all hydraulic and pneumatic fitting needs.
