HC30143 Dixon Steel Hose Cabinet (FM Approved) - 60" x 15" x 48" - Powhatan Part #: 30-143-00001

HC30143 Dixon Steel Hose Cabinet (FM Approved) - 60" x 15" x 48" - Powhatan Part #: 30-143-00001

Save $142.86 Save $142.86
$1,805.43
$1,805.43 - $1,805.43
$1,805.43
$1,662.57
$1,662.57 - $1,662.57
$1,662.57

Dixon Fire Fittings
Racks & Reels - Steel Hose Cabinet

Wall type hose cabinet used for storage for industrial fire protection equipment.

Designed for wall installation, with or without legs, or free standing.

Factory Mutual approved.
Specifications for Variant SKU: HC30143 Dixon
Features:
  • Red polyester coated finish on heavy 18-gauge steel.
  • Supplied with holes in the back for wall mounting and 1" pipe couplings on the bottom for adding legs.
  • Hose or accessories not included.
  • Accessory hardware required but not included.
  • Concrete base is to be supplied by a contractor.
Part Number Width Depth Height Powhatan Part # Weight
(Lbs.)
HC30143 60" 15" 48" 30-143-00001 194.0000


Basic Approved Equipment for house/cabinet
Examples Quantity Required
Part Number Description Factory Mutual UL & FIA ISO
A525-50RAF* 2-1/2" x 50' Single Jacket Hose 4 5 5
A515-50RAF* 1-1/2" x 50' Single Jacket Hose 2 0 0
UPP250F* Underwriters Play Pipe 0 2 2
HA2515F* 2-1/2" x 1-1/2" Pin Lug Adapter 1 0 0
233 Universal Spanner 4 5 5
189 Adjustable Hydrant Wrench 2 2 2
PHFA6 6 lb. Fire Axe 0 1 1
FCB48 Crowbar 0 1 1
SW150* 2-1/2" Hose Coupling Gasket 4 5 5
SW250* 1-1/2" Hose Coupling Gasket 2 0 0

* Threads must be appropriate to the authority having jurisdiction
