IBV100 by Dixon Valve | Ball Valve | Standard Port | 1" Female NPT x 1" Female NPT | Carbon Steel

IBV100 by Dixon Valve | Ball Valve | Standard Port | 1" Female NPT x 1" Female NPT | Carbon Steel

Name: IBV100 by Dixon Valve | Ball Valve | Standard Port | 1" Female NPT x 1" Female NPT | Carbon Steel
Brand: Dixon
SKU: IBV100 Dixon
Price: 86.45 USD
Availability: InStock

Save $57.63

$144.08

$144.08 - $144.08

$144.08

$86.45

$86.45 - $86.45

$86.45

Dixon Valve & Coupling
Ball Valve | Carbon Steel

For control of air, water, oil, and gas in hose or pipe lines.

Quantity

Specifications for Variant SKU: IBV100 Dixon
Shape (Orientation):	Straight
Ends Configuration:	1in Female NPT, 1in Female NPT, Some Ends Match
Material(s):	Carbon Steel
Seal Material(s):	RPTFE

Features:
Blow-out proof stem. Adjustable packing gland.
Materials:
Carbon steel body. Chromium plated ball. RPTFE seat and seal.
Specifications:
Pressure rating: 150 PSI saturated steam.

Part Number	Female NPT x Female NPT	PSI	Port
IBV25	1/4"	2000 PSI	Full
IBV38	3/8"	2000 PSI	Full
IBV50	1/2"	2000 PSI	Standard
IBV75	3/4"	2000 PSI	Standard
IBV100	1"	2000 PSI	Standard
IBV125	1-1/4"	1500 PSI	Standard
IBV150	1-1/2"	1500 PSI	Standard
IBV200	2"	1500 PSI	Standard

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
