STBC475 by Dixon Valve | Style STBC | T-Bolt Clamp | 3/4" Band Width | Hose OD Range: from 4.50" to 4.81" | 300 Stainless Steel Band & Bolt

STBC475 by Dixon Valve | Style STBC | T-Bolt Clamp | 3/4" Band Width | Hose OD Range: from 4.50" to 4.81" | 300 Stainless Steel Band & Bolt

Save $4.45

$11.13

$11.13 - $11.13

$11.13

$6.68

$6.68 - $6.68

$6.68

Dixon Valve
T-Bolt Clamps | Style STBC

Quantity

Specifications for Variant SKU: STBC475 Dixon
Series:	Style STBC
Material(s):	300 Stainless Steel
Clamp Thickness:	0.025
Clamp Width:	0.75
Minimum Clamp I.D.:	4.516
Maximum Clamp I.D.:	4.812

Features:
Can be applied with a standard 7/16" socket wrench. Not for use with pneumatic tools.
Sizes:
Band: 3/4" wide, .025" thick
Materials:
Style TBC 300-series stainless steel band. Alloy steel bolt, torque rating: 70 in. lbs. Style STBC 300-series stainless steel band. 300-series stainless steel bolt, torque rating: 50 in/lbs

Style TBC Part Number	Band Width	Hose OD		Style STBC Part Number	Band Width	Hose OD
Style TBC Part Number	Band Width	From	To	Style STBC Part Number	Band Width
TBC131	3/4"	1.25"	1.406"	STBC131	3/4"	1.25"	1.4063"
TBC150	3/4"	1.34"	1.56"	STBC150	3/4"	1.31"	1.56"
-	-	-	-	STBC163	3/4"	1.44"	1.69"
TBC175	3/4"	1.56"	1.81"	STBC175	3/4"	1.56"	1.81"
TBC188	3/4"	1.69"	1.94"	STBC188	3/4"	1.69"	1.94"
TBC200	3/4"	1.81"	2.06"	STBC200	3/4"	1.81"	2.06"
-	-	-	-	STBC212	3/4"	1.93"	2.18"
TBC225	3/4"	2.06"	2.31"	STBC225	3/4"	2.06"	2.31"
TBC238	3/4"	2.19"	2.5"	STBC238	3/4"	2.19"	2.5"
TBC250	3/4"	2.31"	2.62"	STBC250	3/4"	2.31"	2.62"
TBC256	3/4"	2.31"	2.62"	STBC256	3/4"	2.31"	2.62"
TBC263	3/4"	2.37"	2.68"	STBC263	3/4"	2.37"	2.68"
TBC275	3/4"	2.50"	2.81"	STBC275	3/4"	2.50"	2.81"
TBC288	3/4"	2.63"	2.94"	STBC288	3/4"	2.63"	2.94"
TBC300	3/4"	2.75"	3.06"	STBC300	3/4"	2.75"	3.06"
TBC312	3/4"	2.88"	3.19"	STBC312	3/4"	2.88"	3.19"
TBC325	3/4"	3.00"	3.31"	STBC325	3/4"	3.00"	3.31"
TBC350	3/4"	3.25"	3.56"	STBC350	3/4"	3.25"	3.56"
-	-	-	-	STBC362	3/4"	3.38"	3.69"
TBC375	3/4"	3.50"	3.81"	STBC375	3/4"	3.50"	3.81"
TBC382	3/4"	3.56"	3.87"	STBC382	3/4"	3.56"	3.87"
TBC400	3/4"	3.75"	4.06"	STBC400	3/4"	3.75"	4.06"
TBC425	3/4"	4.00"	4.30"	STBC425	3/4"	4.00"	4.30"
TBC450	3/4"	4.25"	4.56"	STBC450	3/4"	4.25"	4.56"
TBC475	3/4"	4.50"	4.81"	STBC475	3/4"	4.50"	4.81"
TBC500	3/4"	4.75"	5.06"	STBC500	3/4"	4.75"	5.06"
TBC525	3/4"	5.00"	5.31"	STBC525	3/4"	5.00"	5.31"
TBC550	3/4"	5.25"	5.56"	STBC550	3/4"	5.25"	5.56"
TBC575	3/4"	5.50"	5.81"	STBC575	3/4"	5.50"	5.81"
TBC600	3/4"	5.75"	6.06"	STBC600	3/4"	5.75"	6.06"
TBC625	3/4"	6.00"	6.31"	STBC625	3/4"	6.00"	6.31"
TBC650	3/4"	6.25"	6.56"	STBC650	3/4"	6.25"	6.56"
TBC675	3/4"	6.50"	6.81"	STBC675	3/4"	6.50"	6.81"
TBC700	3/4"	6.75"	7.06"	STBC700	3/4"	6.75"	7.06"
-	-	-	-	STBC725	3/4"	7.00"	7.31"
TBC750	3/4"	7.25"	7.56"	STBC750	3/4"	7.25"	7.56"
-	-	-	-	STBC800	3/4"	7.75"	8.06"
-	-	-	-	STBC825	3/4"	8.00"	8.31"
-	-	-	-	STBC850	3/4"	8.25"	8.56"
-	-	-	-	STBC888	3/4"	8.63"	8.94"
-	-	-	-	STBC900	3/4"	8.75"	9.06"
-	-	-	-	STBC950	3/4"	9.25"	9.56"
-	-	-	-	STBC1000	3/4"	9.75"	10.06"
-	-	-	-	STBC1088	3/4"	10.63"	10.94"
-	-	-	-	STBC1200	3/4"	11.75"	12.06"
-	-	-	-	STBC1288	3/4"	12.63"	12.94"

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
