FJ3066-1212S E-Z Clip System by Danfoss | "T" Splicer | 3 Hose Connector | A/C Refrigeration Fitting | -12 Hose Barb x -12 Hose Barb x -12 Hose Barb | Steel
FJ3066-1212S E-Z Clip System by Danfoss | "T" Splicer | 3 Hose Connector | A/C Refrigeration Fitting | -12 Hose Barb x -12 Hose Barb x -12 Hose Barb | Steel
FJ3066-1212S E-Z Clip System by Danfoss | "T" Splicer | 3 Hose Connector | A/C Refrigeration Fitting | -12 Hose Barb x -12 Hose Barb x -12 Hose Barb | Steel
FJ3066-1212S E-Z Clip System by Danfoss | "T" Splicer | 3 Hose Connector | A/C Refrigeration Fitting | -12 Hose Barb x -12 Hose Barb x -12 Hose Barb | Steel

FJ3066-1212S E-Z Clip System by Danfoss | "T" Splicer | 3 Hose Connector | A/C Refrigeration Fitting | -12 Hose Barb x -12 Hose Barb x -12 Hose Barb | Steel

$116.43 - $116.43
$116.43
$116.43 - $116.43
$116.43

Danfoss A/C & Refrigeration
E-Z Clip System - "T" Splicer (3 Hose Connector) - Tee

Clips & Cages Sold Separately.

For use with GH001 EverCool A/C & Refrigeration Hose.
Specifications for Variant SKU: FJ3066-1212S Danfoss
Brand: E-Z Clip
Shape (Orientation): Straight
Ends Configuration: 3/4in Hose Barb, 3/4in Hose Barb, 3/4in Hose Barb, Some Ends Match
Material(s): Steel
Compatible with the following Series: GH001 Series  |   GH134 Series
Additional Information:
Steel
Part Number		 Thread
"T" 		Hose Size A Ref. D Ref. Ref.

 Clip & Cage Kit
(1 Kit Required
for each End)
FJ3066-0606S - -06 5.48" 2.40" - FF14171
FJ3066-060808S - -06 x -08 x -08 5.48" 2.40" - -06: FF14171
-08: FF14172
FJ3066-0808S - -08 5.48" 2.40" - FF14172
FJ3066-1010S - -10 5.62" 2.52" - FF14173
FJ3066-101212S - -10 x -12 x -12 5.67" 2.52" - -10: FF14173
-12: FF14174
FJ3066-1212S - -12 5.67" 2.52" - FF14174
