AWD02012 Tygon® by Saint Gobain | 3/16" ID x 5/16" OD x 1/16" Wall | B-44-0 Tubing | 100' Package Length

Save $1.66 Save $1.66
Original price $16.59
Original price $16.59 - Original price $16.59
Original price $16.59
Current price $14.93
$14.93 - $14.93
Current price $14.93

Saint Gobain
B-44-0 Tubing

No by the foot sales. This is a Packaged Length product.
Can I get a discount on my purchase?

Our listed prices are our lowest possible price with current costing but when volumes/value are high enough sometimes we can pass on a discount from the manufacturer.

Some products have predefined quantity discounts that will apply automatically, those pages have a table near the price describing the discount teirs.

If you feel your purchase quantity of a particular product is very large and want us to investigate with the manufacturer please feel free to Contact Us.

What if my item is out of stock?

All customers get an email regarding the shipping time frame of their purchase, usually within the business day. If your item is in stock we will ship within 1 business day, otherwise, the email will contain a lead time. If you do not receive this email, we recommend checking your email's spam folder. If you have any questions at that point please do not hesitate to Contact Us or chat below!

Can I get free shipping?

Shipping will calculate as free instantly if your order value exceeds $5000.

Some exceptions apply.

Free Freight is only available for the Contiguous USA.

Specifications for Variant SKU: AWD02012 Saint Gobain
Brand: Tygon
Series: B-44-0
Hose Color(s): Clear/Semi-Clear
Internal Diameter: 0.1875in
Outer Diameter: 0.3125in
Tubing Construction: Special Proprietary
Part Number Inside Diameter (in.) Outside Diameter (in.) Wall Thickness (in.) Length
AWD02002 1/16" 1/8" 1/32" 100ft
AWD02007 1/8" 1/4" 1/16" 100ft
AWD02012 3/16" 5/16" 1/16" 100ft
AWD02013 3/16" 3/8" 3/32" 100ft
AWD02014 3/16" 7/16" 1/8" 100ft
AWD02017 1/4" 3/8" 1/16" 100ft
AWD02018 1/4" 7/16" 3/32" 100ft
AWD02019 1/4" 1/2" 1/8" 100ft
AWD02022 5/16" 7/16" 1/16" 100ft
AWD02023 5/16" 1/2" 3/32" 100ft
AWD02027 3/8" 1/2" 1/16" 100ft
AWD02028 3/8" 9/16" 3/32" 100ft
AWD02029 3/8" 5/8" 1/8" 100ft
AWD02032 7/16" 9/16" 1/16" 100ft
AWD02033 7/16" 5/8" 3/32" 100ft
AWD02036 1/2" 5/8" 1/16" 100ft
AWD02037 1/2" 11/16 3/32" 100ft
AWD02038 1/2" 3/4" 1/8" 100ft
AWD02039 1/2" 13/16" 5/32" 100ft
AWD02041 9/16" 3/4 3/32" 100ft
AWD02045 5/8" 13/16" 3/32" 100ft
AWD02046 5/8" 7/8" 1/8" 100ft
AWD02053 3/4" 1 1/8" 100ft
AWD02054 3/4" 1-1/16" 5/32" 100ft
AWD02055 3/4" 1-1/8" 3/16" 100ft
AWD02057 3/4" 1-1/4 1/4" 100ft
AWD02059 7/8" 1-1/8" 1/8" 100ft
AWD00062 1" 1-1/4" 1/8" 50ft
AWD00064 1" 1-3/8 3/16" 50ft
AWD00065 1" 1-1/2" 1/4" 50ft
AWD00070 1-1/4" 1-5/8" 3/16" 50ft
AWD00071 1-1/4" 1-3/4 1/4" 50ft
AWD00073 1-1/2" 1-7/8" 3/16" 50ft
AWD00074 1-1/2" 2" 1/4" 50ft
AWD00076 1-3/4" 2-1/4 1/4" 50ft
AWD00078 2" 2-1/2" 1/4" 50ft
AWD00085 3" 3-1/2" 1/4" 50ft

Note: Every attempt has been taken to provide accurate detailed usable information online, however please consult Saint-Gobain Performance Plastics information documents for the most accurate and up to date data and specifics. Important! It is the user's responsibility to ensure the suitability and safety of Saint-Gobain Performance Plastics tubing for all intended uses. Laboratory and clinical tests must be conducted in accordance with applicable regulatory requirements in order to determine the safety and effectiveness for use of tubing in any particular application. ©2003 Saint-Gobain Performance Plastics Corporation This product is priced and sold by Packaged Length. At this time, this particular hose is not available "by the foot" through our site.
