Tygon® AWD02023 Saint Gobain 5/16" ID x 1/2" OD x 3/32" Wall 100' Package Length - B-44-0 Tubing

AWD02023 Tygon® by Saint Gobain | 5/16" ID x 1/2" OD x 3/32" Wall | B-44-0 Tubing | 100' Package Length

Minimum Order Quantity: 12 Packages

Save $39.52 Save $39.52
$39.52
$39.52 - $39.52
$39.52
$0.00
$0.00 - $0.00
$0.00

Saint Gobain
B-44-0 Tubing

No by the foot sales. This is a Packaged Length product.
Specifications for Variant SKU: AWD02023 Saint Gobain
Brand: Tygon
Series: B-44-0
Hose Color(s): Clear/Semi-Clear
Internal Diameter: 0.3125in
Outer Diameter: 0.5in
Tubing Construction: Special Proprietary
Part Number Inside Diameter (in.) Outside Diameter (in.) Wall Thickness (in.) Length
AWD02002 1/16" 1/8" 1/32" 100ft
AWD02007 1/8" 1/4" 1/16" 100ft
AWD02012 3/16" 5/16" 1/16" 100ft
AWD02013 3/16" 3/8" 3/32" 100ft
AWD02014 3/16" 7/16" 1/8" 100ft
AWD02017 1/4" 3/8" 1/16" 100ft
AWD02018 1/4" 7/16" 3/32" 100ft
AWD02019 1/4" 1/2" 1/8" 100ft
AWD02022 5/16" 7/16" 1/16" 100ft
AWD02023 5/16" 1/2" 3/32" 100ft
AWD02027 3/8" 1/2" 1/16" 100ft
AWD02028 3/8" 9/16" 3/32" 100ft
AWD02029 3/8" 5/8" 1/8" 100ft
AWD02032 7/16" 9/16" 1/16" 100ft
AWD02033 7/16" 5/8" 3/32" 100ft
AWD02036 1/2" 5/8" 1/16" 100ft
AWD02037 1/2" 11/16 3/32" 100ft
AWD02038 1/2" 3/4" 1/8" 100ft
AWD02039 1/2" 13/16" 5/32" 100ft
AWD02041 9/16" 3/4 3/32" 100ft
AWD02045 5/8" 13/16" 3/32" 100ft
AWD02046 5/8" 7/8" 1/8" 100ft
AWD02053 3/4" 1 1/8" 100ft
AWD02054 3/4" 1-1/16" 5/32" 100ft
AWD02055 3/4" 1-1/8" 3/16" 100ft
AWD02057 3/4" 1-1/4 1/4" 100ft
AWD02059 7/8" 1-1/8" 1/8" 100ft
AWD00062 1" 1-1/4" 1/8" 50ft
AWD00064 1" 1-3/8 3/16" 50ft
AWD00065 1" 1-1/2" 1/4" 50ft
AWD00070 1-1/4" 1-5/8" 3/16" 50ft
AWD00071 1-1/4" 1-3/4 1/4" 50ft
AWD00073 1-1/2" 1-7/8" 3/16" 50ft
AWD00074 1-1/2" 2" 1/4" 50ft
AWD00076 1-3/4" 2-1/4 1/4" 50ft
AWD00078 2" 2-1/2" 1/4" 50ft
AWD00085 3" 3-1/2" 1/4" 50ft

Note: Every attempt has been taken to provide accurate detailed usable information online, however please consult Saint-Gobain Performance Plastics information documents for the most accurate and up to date data and specifics. Important! It is the user's responsibility to ensure the suitability and safety of Saint-Gobain Performance Plastics tubing for all intended uses. Laboratory and clinical tests must be conducted in accordance with applicable regulatory requirements in order to determine the safety and effectiveness for use of tubing in any particular application. ©2003 Saint-Gobain Performance Plastics Corporation This product is priced and sold by Packaged Length. At this time, this particular hose is not available "by the foot" through our site.

Saint Gobain

Saint Gobain

Saint-Gobain Performance Plastics is one of the world’s leading producers of engineered, high-performance polymer products, and serves virtually every major industry across the globe. Saint-Gobain Performance Plastics businesses support these key industries with advanced technology polymer products for the most demanding applications.
