1-1/2" SP580 Couplamatic Four Spiral High Pressure Hydraulic Hose (Caterpillar) - 4 Spirals (SAE 100R12) - 1-1/2" ID - 50ft

1-1/2" SP580 by Couplamatic | Four Spiral High Pressure Hydraulic Hose | Caterpillar | 4 Spirals | SAE 100R12 | 1-1/2" ID | 50ft

Save $161.58

$1,454.25

$1,454.25 - $1,454.25

$1,454.25

$1,292.67

$1,292.67 - $1,292.67

$1,292.67

Couplamatic Systems Inc.
4 Spirals - SP580 Four Spiral High Pressure Hydraulic Hose (Caterpillar) - (SAE 100R12)

Package Quantity: 50 FT

Quantity

Specifications for Variant SKU: 1-1/2" SP580 Couplamatic \| 50 \|
Series:	SP580 Series
Hose Color(s):	Black
Dash Size:	-24
Internal Diameter:	1.50in
Outer Diameter:	2.105in
Applicable Specs & Approvals:	Applicable MSHA Standards, SAE 100R12
Compatible with the following Series:	GW Series \| 4GC Series

Applications:	High Pressure Hydraulics, Industrial or Agricultural	SAE Rating:	SAE 100R12
Cover:	Abrasion and Flame Resistant Black Cover, MSHA approved	Reinforcement:	4 Spirals
Temperature:	-40F to +250F (-40C to +121C)

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Coil Footage
1/2" SP580	1/2"	0.935"	4,000 lbs.	16,000 lbs.	3.5"	50 lbs.	50ft
3/4" SP580	3/4"	1.210"	4,000 lbs.	16,000 lbs.	4.75"	81 lbs.	50ft
1" SP580	1"	1.495"	4,000 lbs.	16,000 lbs.	6"	119 lbs.	50ft
1-1/4" SP580	1-1/4"	1.850"	3,000 lbs.	12,000 lbs.	8.25"	155 lbs.	50ft
1-1/2" SP580	1-1/2"	2.105"	2,500 lbs.	10,000 lbs.	10"	181 lbs.	50ft
2" SP580	2"	2.626"	2,500 lbs.	10,000 lbs.	12.5"	256 lbs.	50ft
