1/2" R17R Couplamatic Import 3000 PSI Two Wire Hydraulic Hose (SAE 100R17) (1SN Dimension) - 1/2" ID - 350ft

1/2" R17R by Couplamatic | Import 3000 PSI | Two Wire Hydraulic Hose | SAE 100R17 | 1SN Dimension | 1/2" ID | 350ft

Save $599.82

$1,499.55

$1,499.55 - $1,499.55

$1,499.55

$899.73

$899.73 - $899.73

$899.73

Couplamatic Systems Inc.
One or Two Wire Braids Hoses - R17R Import 3000 PSI Constant Working Pressure Hydraulic Hose -(SAE 100R17) (1SN Dimension)

Package Quantity: 350 FT

Specifications for Variant SKU: 1/2" R17R Couplamatic \| 350 \|
Series:	R17R Series
Hose Color(s):	Black
Dash Size:	-8
Internal Diameter:	0.50in
Outer Diameter:	0.812in
Applicable Specs & Approvals:	Applicable MSHA Standards, SAE 100R17
Compatible with the following Series:	Vari-Crimp Series \| A Series \| Grip Crimp Series

SAE 100R17 — 1SN Dimension

R17R Import 3000 PSI Constant Working Pressure Hydraulic Hose

Import SAE 100R17 hose built to 1SN outside diameters, holding a constant 3,000 PSI working pressure through 1/2".

1

What is this hose used for?

High Pressure Hydraulics
Industrial
Agricultural

2

What are the key specifications?

SAE Rating

SAE 100R17 (1SN DIMENSION)

Cover

Abrasion and Flame Resistant Cover, MSHA Approved

Reinforcement

One (1/4"-3/8") or Two (1/2") Wire Braids

Temperature

-40°F to +212°F (-40°C to +100°C)

3

What are the main product features?

3000 PSI constant working pressure — same rating across every size.
1SN dimensions — standard 1SN outside diameters for familiar fitting and clamp sizing.
One or two wire braids — one wire in 1/4" and 3/8", two wire in 1/2".
MSHA approved cover — abrasion and flame resistant.

4

Which sizes are available?

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Reel Footage
1/4" R17R	1/4"	0.530"	3,000 lbs.	12,000 lbs.	2"	16 lbs.	500ft
3/8" R17R	3/8"	0.687"	3,000 lbs.	12,000 lbs.	3"	23 lbs.	500ft
1/2" R17R	1/2"	0.812"	3,000 lbs.	12,000 lbs.	3.5"	31 lbs.	350ft

i

Sold as bulk hose by the reel or coil. Reel and coil footage for each size is listed in the size chart above; cut lengths and hose assemblies are available — contact us for pricing.

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
