1" DHEX16 Couplamatic DURA-HYD EX Super Abrasion Resistant R16/2SC Extra Hi-Pressure Hydraulic Hose (SAE 100R16/2SC) - 1" ID - 200ft

1" DHEX16 by Couplamatic | DURA-HYD EX Super Abrasion Resistant | R16/2SC Extra Hi-Pressure Hydraulic Hose | SAE 100R16/2SC | 1" ID | 200ft

Save $817.78

$2,044.45

$2,044.45 - $2,044.45

$2,044.45

$1,226.67

$1,226.67 - $1,226.67

$1,226.67

Couplamatic Systems Inc.
Two Wire Braid Hoses - DHEX16 Ex Super Abrasion Resistant R16/2SC Extra Hi-Pressure Hydraulic Hose - (SAE 100R16/2SC)

Package Quantity: 200 FT

Specifications for Variant SKU: 1" DHEX16 Couplamatic \| 200 \|
Series:	DHEX16 Series
Hose Color(s):	Black
Dash Size:	-16
Internal Diameter:	1in
Outer Diameter:	1.405in
Applicable Specs & Approvals:	Applicable MSHA Standards, SAE 100R16
Compatible with the following Series:	Vari-Crimp Series \| A Series \| Grip Crimp Series

SAE 100R16/2SC — Super Abrasion Resistant

Dura-Hyd EX Super Abrasion Resistant Hydraulic Hose

Two-wire SAE 100R16/2SC hose with a flame resistant bi-layer cover engineered for heavy external abrasion, for equipment where standard covers wear through.

1

What is this hose used for?

High Pressure Hydraulics
Industrial
Agricultural

2

What are the key specifications?

SAE Rating

SAE 100R16/2SC

Cover

Flame Resistant Bi-Layer, SUPER Abrasion Resistant, MSHA

Reinforcement

Two Wire Braids

Temperature

-40°F to +212°F (-40°C to +100°C)

3

What are the main product features?

Bi-layer cover — SUPER abrasion resistant construction for severe external wear.
Flame resistant, MSHA — approved for mining and other demanding environments.
Two wire braids — full SAE 100R16 / DIN 2SC working pressures.
Compact OD — same outside diameters as standard R16, so existing routing and clamps still fit.

4

Which sizes are available?

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Reel Footage
1/4" DHEX16	1/4"	0.530"	5,800 lbs.	23,200 lbs.	2"	18 lbs.	500ft
3/8" DHEX16	3/8"	0.687"	5,000 lbs.	20,000 lbs.	2.5"	27 lbs.	400ft
1/2" DHEX16	1/2"	0.812"	4,250 lbs.	17,000 lbs.	3.5"	35 lbs.	300ft
5/8" DHEX16	5/8"	0.937"	3,625 lbs.	14,500 lbs.	4"	40 lbs.	250ft
3/4" DHEX16	3/4"	1.090"	3,125 lbs.	12,500 lbs.	4.8"	54 lbs.	250ft
1" DHEX16	1"	1.405"	2,500 lbs.	10,000 lbs.	6"	74 lbs.	200ft

i

Sold as bulk hose by the reel or coil. Reel and coil footage for each size is listed in the size chart above; cut lengths and hose assemblies are available — contact us for pricing.
