130H43 by RuB Inc. | Full Port Ball Valve | 1-1/2" Female NPT x 1-1/2" Female NPT | with Oval Locking Blue Handle | Stainless Steel | Pack of 4

Save $159.21

$557.24

$557.24 - $557.24

$557.24

$398.03

$398.03 - $398.03

$398.03

RuB Inc. - Stainless Steel Ball Valves - S.130 Series - Female NPT x Female NPT - Full Port with Oval Locking Blue Handle

Package Quantity: 4 Units

Specifications for Variant SKU: 130H43 RuB Inc \| 4 \|
Shape (Orientation):	Straight
Ends Configuration:	1-1/2in Female NPT, 1-1/2in Female NPT, Some Ends Match
Material(s):	Stainless Steel
Seal Material(s):	PTFE

Quality:
Dual sealing system allows valve to be operated in either direction making installation easier Handle clearly shows ball position Silicone-free lubricant on all seals Test standard API 598 NACE compliance MR-01-75 Handle stops on body to avoid stresses at stem
Body:
CF8M stainless steel body and cap
Stem:
Blowout-proof stainless steel stem
Sealing:
Glass filled PTFE seats
Threads:
NPT taper ANSI B.1.20.1 female by female threads
Flow:
100% full port for maximum flow
Handle:
Plastic coated stainless steel lockable handle. Handle coating offers both thermal and electrical protection WARNING: do not exceed reasonable temperature and/or electrical load Handle removable with valve in service
Working Pressure & Temperature:
1000 PSI non-shock cold working pressure 150 PSI WSP steam rating 2x 10^-2 torr vacuum rating *150 psig non-shock working steam pressure. Not suitable for throttling steam. -50°F/ +450°F WARNING: freezing of the fluid in the installation may severely damage the valve
Approved by or in compliance with:
GOST-R (Russia) NOTE: approvals apply to specific configurations/sizes only.


Part Number	Size	Dimensions (Inches)
Part Number	Size	D	d	L	H	D1	W1	h
130B43	1/4"	1/4"	0.433"	2.276"	2.252"	4.055"	N/A	N/A
130C43	3/8"	3/8"	0.492"	2.276"	2.252"	4.055"	N/A	N/A
130D43	1/2"	1/2"	0.591"	2.429"	2.327"	4.055"	N/A	N/A
130E43	3/4"	3/4"	0.787"	2.76"	2.463"	4.055"	N/A	N/A
130F43	1"	1"	0.984"	3.201"	2.783"	5"	N/A	N/A
130G43	1-1/4"	1-1/4"	1.26"	3.78"	3"	5"	N/A	N/A
130H43	1-1/2"	1-1/2"	1.496"	4.429"	3.508"	6.024"	N/A	N/A
130I43	2"	2"	1.969"	4.961"	3.864"	7.598"	N/A	N/A

RuB Inc

RuB is a manufacturer of shut-off brass valves with focus on ball valves for gas, water, air, oil installations. Great emphasis is put on quality: ISO 9001 and PED compliance are guaranteed by well known organizations and many major international manufacturers rely on RuB. Our products are designed with long life and reliability criteria.
