1711X4 by Danfoss | SelfAlign Adapter | Male Pipe Run Tee | Long Nut | 1/4" Tube OD x 1/8" Male NPTF x 1/4" Tube OD | Brass

$22.77 - $22.77

$22.77

$22.77 - $22.77

$22.77

Aeroquip® by Danfoss
SelfAlign Adapter - Male Pipe Run Tee (with Long Nut)
SelfAlign End x Male NPTF x SelfAlign End

Specifications for Variant SKU: 1711X4 Danfoss
Shape (Orientation):	Tee
Material(s):	Brass

Applications:
Instrumentation, hydraulic and pneumatic systems.
Advantages:
Very low cost and reusable. Self aligning - no need to disassemble fitting to line up sleeve on tube. Low cost. Easy to assemble, no flaring. Good vibration resistance - use long nut when greater vibration resistance is needed.
Used With:
Aluminum, copper and plastic tubing. Plastic tubing, except for PT230 and TP160, requires 2030x insert. Not recommended for steel tubing.
Material:
CA360 Brass
Pressure:
Working pressure up to 2000 psi with a 4:1 safety factor depending on tube size. When using plastic tubing, use the working pressure for type used.
Temperature Range:
-65°F to +250°F (-53°C to +121°C) with metal tubing. When using compatible plastic tubing do not exceed the tubing temperature range.
Conformance:
An exclusive product design, user approvals only

Brass Part Number	Tube O.D.	Male Pipe Thread
1711X4	1/4"	1/8"

Danfoss (Eaton - Aeroquip)

Danfoss is a global technology leader in power management solutions that make electrical, hydraulic and mechanical power operate more efficiently, reliably, safely and sustainably. Danfoss hydraulic pumps, motors, transmissions, valves, cylinders, controls, hose and fittings offer a unique combination of proven technology and innovative design that translates directly into reliable performance and enhanced uptime.
