2200210 (10B) by PT-Coupling | Corrosion Resistant Cam & Groove Adapter | Type B | 1" Coupler x 1" Male NPT | Monel | Buna-N Seal

2200210 (10B) by PT-Coupling | Corrosion Resistant Cam & Groove Coupler | Type B | 1" Coupler x 1" Male NPT | Monel | Buna-N Seal

Save $68.30

$183.98

$183.98 - $183.98

$183.98

$115.68

$115.68 - $115.68

$115.68

PT Coupling
Corrosion Resistant Cam & Groove (Camlock) Adapter | Type B | Coupler x Male NPT | Monel | Buna-N Seal

These corrosion resistant cam & groove couplings are designed for acid applications in highly corrosive media including hydrochloric acid and sulfuric acid.

Made in the USA

Specifications for Variant SKU: 2200210 PT-Coupling
Shape (Orientation):	Straight
Cam Type:	Type B
Ends Configuration:	1in Female Cam & Groove, 1in Male NPT
Material(s):	Monel
Seal Material(s):	Buna-N/Nitrile

Features & Applications:
These corrosion resistant cam & groove couplings are designed for acid applications in highly corrosive media including hydrochloric acid and sulfuric acid. Made in the USA


Part Name	Item #	Coupler Size	Male NPT Thread	O. D. with Cam Arms Extended (A)	Outside Diameter (B)	Overall Length (C)	Exposed Length (D)	Inside Diameter (E)	Max. Allowable Working Press. (PSI)*
10B	2200210	1"	1"	5.10"	2.44"	2.50"	1.56"	0.97"	250 PSI

*Above maximum allowable working pressures are based on operating temperatures less than 100°F.

PT-Coupling

PT Coupling is a renowned manufacturer of Cam & Groove fittings, Punch-Lok banding, and clamps for industrial hoses. Established in 1951, the company offers a range of products made from different materials and is known for their innovative proprietary Punch-Lok design. PT Coupling's products are trusted by customers worldwide in various industries, such as agriculture, construction, and mining. With a commitment to quality and customer service, PT Coupling continues to be a leading producer of industrial hose fittings.
