2770107 (07A) by PT-Coupling | Cam & Groove Adapter | Type A | 3/4" Adapter x 3/4" Female NPT | Food Grade Polypropylene

2770107 (07A) by PT-Coupling | Cam & Groove Adapter | Type A | 3/4" Adapter x 3/4" Female NPT | Food Grade Polypropylene

Save $5.03 Save $5.03
$13.55
$13.55 - $13.55
$13.55
$8.52
$8.52 - $8.52
$8.52

PT Coupling
Cam and Groove (Camlock) Adapter | Type A | Adapter x Female NPT Thread | Food Grade Polypropylene

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA
Specifications for Variant SKU: 2770107 PT-Coupling
Shape (Orientation): Straight
Cam Type: Type A
Ends Configuration: 3/4in Male Cam & Groove, 3/4in Female NPT
Material(s): Food Grade Polypropylene
Overview:
  • PT Quick Connect/Disconnect Couplings provide for quick connecting and disconnecting by means of the camming action. This camming action allows pipe and hose connections to be made without the need of hand tools or difficult threaded connections. Cam and groove couplings are made up of two parts, male (adapter/plug) and female (coupler/socket) that work together. The male adapter is simply inserted into the female coupler until contact is made with the gasket. Both cam arms on the coupler are then pressed down/closed simultaneously to produce a uniform gasket compression between the seal surfaces. This seal is created because the cam arms of the female coupler fit snugly against the groove of the male adapter. A positive seal requires that the surfaces on the gasket seat, the adapter face, and the gasket are smooth and uncontaminated. Also cam arms must be in the full closed position for proper locking of the coupling. To disconnect both arms must be lifted / opened simultaneously to release the seal and release the connection.
Features & Applications:
  • Fair abrasion resistance
  • Color: White.
  • Use with water and other food grade applications.
  • Made in the USA
Part Name Item # Adapter
Size		 Thread
(Female NPT)		 Overall
Length
(C)		 Inside
Diameter
(E)		 Across
Corners
(F)		 Chain Lug
Extension
(G)		 Engagement
Length		 Max. Allowable
Working Press.
(PSI)*		 Weight
07A 2770107 3/4" 3/4" 1.62" 0.75" 1.49" - 0.97" 100 PSI 0.07 lbs.
10A 2770110 1" 1" 1.91" 0.88" 1.76" 0.34" 1.19" 100 PSI 0.095 lbs.
12A 2770112 1-1/4" 1-1/4" 2.16" 1.04" 2.19" 0.34" 1.44" 100 PSI 0.125 lbs.
15A 2770115 1-1/2" 1-1/2" 2.29" 1.35" 2.44" 0.33" 1.48" 100 PSI 0.17 lbs.
20A 2770120 2" 2" 2.54" 1.72" 2.92" 0.31" 1.75" 100 PSI 0.225 lbs.
30A 2770130 3" 3" 2.84" 2.80" 4.22" 0.44" 1.84" 50 PSI 0.415 lbs.
40A 2770140 4" 4" 3.16" 3.78" 5.41" 0.39" 1.87" 50 PSI 0.8 lbs.

*Above maximum allowable working pressures are based on operating temperatures less than 100°F.
