28719 (28-719) Midland JIC 37° Flare - Straight - 1" Tube OD - 3/4-14" Male NPTF - 1-5/16-12 Tube Thread - Brass

28719 by Midland | JIC 37° Flare | 1" Tube OD | 3/4-14" Male NPTF | 1-5/16-12 Tube Thread | Straight | Brass

Save $2.98

$26.83

$26.83 - $26.83

$26.83

$23.85

$23.85 - $23.85

$23.85

Midland Industries
Brass Fitting - JIC 37° Flare - Male JIC 37° Flare x Male NPTF - Brass

Quantity

Specifications for Variant SKU: 28719 Midland
Shape (Orientation):	Straight
Material(s):	Brass

Crossover Series:
B2404	SB	FTXB

Part Number	Tube OD	A NPTF	Tube Thread	Length	Hex	Working Pressure
28701 (28-701)	1/4"	1/8-27	7/16-20	1.22"	0.45"	3250 PSI
28702 (28-702)	1/4"	1/4-18	7/16-20	1.37"	0.56"	3250 PSI
28703 (28-703)	1/4"	3/8-18	7/16-20	1.42"	0.75"	3250 PSI
28704	5/16"	1/8-27	1/2-20	1.41"	0.56"	3250 PSI
28705 (28-705)	5/16"	1/4-18	1/2-20	1.42"	0.56"	3250 PSI
28706 (28-706)	3/8"	1/8-27	9/16-18	1.24"	0.63"	3250 PSI
28707 (28-707)	3/8"	1/4-18	9/16-18	1.43"	0.63"	3250 PSI
28708 (28-708)	3/8"	3/8-18	9/16-18	1.38"	0.75"	3250 PSI
28709 (28-709)	3/8"	1/2-14	9/16-18	1.69"	0.88"	3250 PSI
28710 (28-710)	1/2"	1/4-18	3/4-16	1.53"	0.81"	3250 PSI
28711 (28-711)	1/2"	3/8-18	3/4-16	1.53"	0.81"	3250 PSI
28712 (28-712)	1/2"	1/2-14	3/4-16	1.79"	0.88"	3250 PSI
28713 (28-713)	1/2"	3/4-14	3/4-16	1.85"	1.13"	2600 PSI
28714	5/8"	3/8	7/8-14	1.84"	0.94"	3250 PSI
28715 (28-715)	5/8"	1/2-14	7/8-14	1.89"	0.94"	3250 PSI
28716 (28-716)	5/8"	3/4-14	7/8-14	1.95"	1.13"	2600 PSI
28748 (28-748)	3/4"	1/2-14	1-1/16-12	2.06"	1.13"	2925 PSI
28717 (28-717)	3/4"	3/4-14	1-1/16-12	2.06"	1.13"	2600 PSI
28749 (28-749)	3/4"	1-11-1/2	1-1/16-12	2.25"	1.38"	1950 PSI
28719 (28-719)	1"	3/4-14	1-5/16-12	2.06"	1.13"	2275 PSI
28718 (28-718)	1"	1-11-1/2	1-5/16-12	2.30"	1.38"	1950 PSI

Midland Industries

Midland Industries is a family of brands recognizable industry wide. Midland is a supplier of brass fittings, valves, and accessories for hose, pipe and tube in brass, bronze, stainless steel, steel, malleable iron, and plastics.
