29-5L10-M by Coilhose | 29 Series Lubricator | Manual | HiFlow | Metal Bowl | 1" Pipe Size | Aluminum

Save $15.24

$137.17

$137.17 - $137.17

$137.17

$121.93

$121.93 - $121.93

$121.93

Coilhose Pneumatics - Filters, Regulators & Lubricators - 29 Series - Lubricators

Quantity

Specifications for Variant SKU: 29-5L10-M Coilhose
Material(s):	Aluminum

Overview:
The 29 Series of Filters - Regulators - Lubricators are made from lightweight aluminum bodies, which lend themselves to a wide variety of applications. These filters, regulators and lubricators are also "modular" in design, meaning the individual units can be removed from the line without disturbing the piping or other components. The 29 Series modular connecting system is designed to save space, making it ideal for OEM equipment as well as suitable for tight areas in shop or factory air lines and assembly areas.
Features:
Modular design Metal bowl option
Warning:
Although polycarbonate bowls are capable of withstanding extreme physical abuse, they are susceptible to damage and may possibly burst when subjected to some cleaning products and synthetic oils, particularly phosphate esters. Should there be any questions regarding their compatibility with your applications, consult the factory or use a metal bowl.

Proof Pressure:	220 PSI	Max Operating Pressure:	145 PSI
Maximum Operating Temp.:	Plastic Bowl: 140° F Metal Bowl: 150° F	Ambient & Fluid Temp:	32° F to 140° F
Materials:	Plastic Bowl: Polycarbonate Metal Bowl¹: Aluminum Body: Aluminum	Bowl Guard²	Steel

ManualModel	Pipe Size	Max. FlowRate CFM	Min. OperatingFlow	BowlCapacity	Features
29-2L18	1/8"	28	0.53	1.1 oz	Mini
29-2L18-M	1/8"	28	0.53	1.1 oz	Mini, Metal Bowl
29-2L14	1/4"	28	0.53	1.1 oz	Mini
29-2L14-M	1/4"	28	0.53	1.1 oz	Mini, Metal Bowl
29-3L14	1/4"	60	1.1	5 oz	Compact
29-3L14-M	1/4"	60	1.1	5 oz	Compact, Metal Bowl
29-3L38	3/8"	60	1.4	5 oz	Compact
29-3L38-M	3/8"	60	1.4	5 oz	Compact, Metal Bowl
29-4L38	3/8"	175	1.8	16 oz	Standard
29-4L38-M	3/8"	175	1.8	16 oz	Standard, Metal Bowl
29-4L12	1/2"	175	1.8	16 oz	Standard
29-4L12-M	1/2"	175	1.8	16 oz	Standard, Metal Bowl
29-5L34	3/4"	250	6.7	16 oz	HiFlow
29-5L34-M	3/4"	250	6.7	16 oz	HiFlow, Metal Bowl
29-5L10	1"	250	6.7	16 oz	HiFlow
29-5L10-M	1"	250	6.7	16 oz	HiFlow, Metal Bowl

¹Metal bowl is available on all series
²No bowl guard on Series 2L
