3/4" 024H Couplamatic Rubber Covered Push-on Hose - One Fiber Braid - Blue - 3/4" ID - 500ft

3/4" 024H by Couplamatic | Rubber Covered Push-on Hose | One Fiber Braid | Blue | 3/4" ID | 500ft

Save $1,624.45

$4,061.12

$4,061.12 - $4,061.12

$4,061.12

$2,436.67

$2,436.67 - $2,436.67

$2,436.67

Couplamatic Systems Inc.
One Fiber Braid - 025H Rubber Covered Push-on Hose

Package Quantity: 500 FT

Specifications for Variant SKU: 3/4" 024H Couplamatic \| 500 \|
Series:	024H Series
Hose Color(s):	Blue
Internal Diameter:	0.75in
Outer Diameter:	1.031in
Cover Construction:	Rubber

Push-On Hose — Blue Rubber Cover

024H Rubber Covered Push-On Hose

Low pressure one fiber braid push-on hose with a blue oil resistant rubber cover — the blue jacket makes it easy to keep separate from black push-on lines.

1

What is this hose used for?

Low Pressure

2

What are the key specifications?

Cover

Blue Oil Resistant Rubber

Reinforcement

One Fiber Braid

Temperature

-40 to +190°F (-40 to +88°C)

Size Range

1/4" to 3/4"

3

What are the main product features?

No clamps or crimping — assembles by hand onto push-on fittings.
Blue cover — distinguishes this line at a glance from black push-on hose.
Oil resistant rubber cover — shop air, fuel, oil and general low pressure service.
Cut lengths available — 100ft minimum.

4

Which sizes are available?

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Coil Footage
1/4" 024H	1/4"	0.500"	300 lbs.	1,200 lbs.	2.5"	9 lbs.	500ft
3/8" 024H	3/8"	0.640"	300 lbs.	1,200 lbs.	3"	11 lbs.	500ft
1/2" 024H	1/2"	0.750"	300 lbs.	1,200 lbs.	5"	13 lbs.	500ft
5/8" 024H	5/8"	0.910"	300 lbs.	1,200 lbs.	6"	19 lbs.	500ft
3/4" 024H	3/4"	1.031"	300 lbs.	1,200 lbs.	7"	21 lbs.	500ft

i

Cut lengths are available with a 100ft minimum. Sold as bulk hose by the reel or coil. Reel and coil footage for each size is listed in the size chart above; cut lengths and hose assemblies are available — contact us for pricing.

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
