4103-0037-328 by Jason Industrial | 4103 Series | Air Hose | Medium Oil Resistant | 300 PSI | 3/8"" ID | 0.59" OD | Red | PVC | 328ft

4103-0037-328 by Jason Industrial | 4103 Series | Air Hose | Medium Oil Resistant | 300 PSI | 3/8"" ID | 0.59" OD | Red | PVC | 328ft

Save $58.20 Save $58.20
$203.71
$203.71 - $203.71
$203.71
$145.51
$145.51 - $145.51
$145.51

Jason Industrial Inc. Hose - Air Hose - 4103 Red PVC Air Hose - Medium Oil Resistant

Package Quantity: 328 FT

Specifications for Variant SKU: 4103-0037-328 Jason | 328 |
Series: 4103 Series
Hose Color(s): Red
Internal Diameter: 0.375in
Outer Diameter: 0.59in
Tubing Construction: PVC
Cover Construction: PVC

SPECIFICATIONS

Application: General purpose use, including air, water and mild chemical applications. SAE Rating: N/A
Other Ratings: ARPM Class C Tube: PVC, Smooth, Medium Oil Resistance, ARPM Class C
Reinforcement: Single Braid, Synthetic Cover: PVC, Smooth, Medium Oil Resistance, ARPM Class C
Temperature Range: -15 deg. F (-26 deg. C) to +150 deg. F (+66 deg. C) Crimp Fittings: N/A
Reusable Fittings: N/A Branding: ID XX" (XXmm) Jason logo WP PSI 4103 (Country of Origin)
Other Features:
  • Oil mist resistant tube
  • Non-marking cover
  • Ozone and weather resistant
  • Resistant to ultra-violet (UV) light rays
Part Number I.D. O.D. Reinforcement Braids Max. Working Press. @ 68 deg. F Vacuum @ 68 deg. F Weight Min. Bend Radius Standard Length
in. mm in. mm PSI BAR lb./ft. KG/m in. mm ft
Uncoupled
4103-0025-328 1/4" 6.35mm 0.44" 11.18mm 1 300 PSI 20.68 BAR N/A 0.07 lb./ft. 0.10 KG/m 1.70" 43.20mm 328ft
4103-0031-328 5/16" 7.94mm 0.50" 12.70mm 1 300 PSI 20.68 BAR N/A 0.08 lb./ft. 0.12 KG/m 2.10" 53.30mm 328ft
4103-0037-328 3/8" 9.53mm 0.59" 14.99mm 1 300 PSI 20.68 BAR N/A 0.10 lb./ft. 0.15 KG/m 2.50" 63.50mm 328ft
4103-0050-328 1/2" 12.70mm 0.75" 19.05mm 1 300 PSI 20.68 BAR N/A 0.16 lb./ft. 0.24 KG/m 3.30" 83.80mm 328ft
4103-0062-328 5/8" 15.88mm 0.91" 23.11mm 1 300 PSI 20.68 BAR N/A 0.22 lb./ft. 0.33 KG/m 4.20" 106.70mm 328ft
4103-0075-164 3/4" 19.05mm 1.05" 26.59mm 1 215 PSI 14.81 BAR N/A 0.28 lb./ft. 0.42 KG/m 5.00" 127.00mm 164ft
4103-0100-164 1" 25.40mm 1.33" 33.73mm 1 170 PSI 11.71 BAR N/A 0.41 lb./ft. 0.61 KG/m 6.70" 170.20mm 164ft
Coupled 1/4" Male NPT x 1/4" Male NPT x 50' Hose Assembly
4103-037450 3/8" 9.53mm 0.59" 14.99mm 1 300 PSI 20.68 BAR N/A 0.10 lb./ft. 0.15 KG/m 2.50" 63.50mm 50ft
Working pressure is temperature dependent. Jason Industrial Inc. disclaims any liability for use of their products in applications other than which they are designed.

Jason Industrial

Founded in 1958 in Fairfield, NJ, Jason Industrial quickly gained a solid reputation as a go to source for both industrial hose and power transmission belts. Jason Industrial offers a comprehensive portfolio of industrial hose, couplings and accessories along with hydraulic hose, fittings and crimping equipment.
