4103-0100-164 by Jason Industrial | 4103 Series | Air Hose | Medium Oil Resistant | 170 PSI | 1" ID | 1.33" OD | Red | PVC | 164ft

4103-0100-164 by Jason Industrial | 4103 Series | Air Hose | Medium Oil Resistant | 170 PSI | 1" ID | 1.33" OD | Red | PVC | 164ft

Save $117.53 Save $117.53
$411.36
$411.36 - $411.36
$411.36
$293.83
$293.83 - $293.83
$293.83

Jason Industrial Inc. Hose - Air Hose - 4103 Red PVC Air Hose - Medium Oil Resistant

Package Quantity: 164 FT

Specifications for Variant SKU: 4103-0100-164 Jason | 164 |
Series: 4103 Series
Hose Color(s): Red
Internal Diameter: 1in
Outer Diameter: 1.33in
Tubing Construction: PVC
Cover Construction: PVC

SPECIFICATIONS

Application: General purpose use, including air, water and mild chemical applications. SAE Rating: N/A
Other Ratings: ARPM Class C Tube: PVC, Smooth, Medium Oil Resistance, ARPM Class C
Reinforcement: Single Braid, Synthetic Cover: PVC, Smooth, Medium Oil Resistance, ARPM Class C
Temperature Range: -15 deg. F (-26 deg. C) to +150 deg. F (+66 deg. C) Crimp Fittings: N/A
Reusable Fittings: N/A Branding: ID XX" (XXmm) Jason logo WP PSI 4103 (Country of Origin)
Other Features:
  • Oil mist resistant tube
  • Non-marking cover
  • Ozone and weather resistant
  • Resistant to ultra-violet (UV) light rays
Part Number I.D. O.D. Reinforcement Braids Max. Working Press. @ 68 deg. F Vacuum @ 68 deg. F Weight Min. Bend Radius Standard Length
in. mm in. mm PSI BAR lb./ft. KG/m in. mm ft
Uncoupled
4103-0025-328 1/4" 6.35mm 0.44" 11.18mm 1 300 PSI 20.68 BAR N/A 0.07 lb./ft. 0.10 KG/m 1.70" 43.20mm 328ft
4103-0031-328 5/16" 7.94mm 0.50" 12.70mm 1 300 PSI 20.68 BAR N/A 0.08 lb./ft. 0.12 KG/m 2.10" 53.30mm 328ft
4103-0037-328 3/8" 9.53mm 0.59" 14.99mm 1 300 PSI 20.68 BAR N/A 0.10 lb./ft. 0.15 KG/m 2.50" 63.50mm 328ft
4103-0050-328 1/2" 12.70mm 0.75" 19.05mm 1 300 PSI 20.68 BAR N/A 0.16 lb./ft. 0.24 KG/m 3.30" 83.80mm 328ft
4103-0062-328 5/8" 15.88mm 0.91" 23.11mm 1 300 PSI 20.68 BAR N/A 0.22 lb./ft. 0.33 KG/m 4.20" 106.70mm 328ft
4103-0075-164 3/4" 19.05mm 1.05" 26.59mm 1 215 PSI 14.81 BAR N/A 0.28 lb./ft. 0.42 KG/m 5.00" 127.00mm 164ft
4103-0100-164 1" 25.40mm 1.33" 33.73mm 1 170 PSI 11.71 BAR N/A 0.41 lb./ft. 0.61 KG/m 6.70" 170.20mm 164ft
Coupled 1/4" Male NPT x 1/4" Male NPT x 50' Hose Assembly
4103-037450 3/8" 9.53mm 0.59" 14.99mm 1 300 PSI 20.68 BAR N/A 0.10 lb./ft. 0.15 KG/m 2.50" 63.50mm 50ft
Working pressure is temperature dependent. Jason Industrial Inc. disclaims any liability for use of their products in applications other than which they are designed.
