5/16" (6) F204 Couplamatic -06 Refrigerant Hose - Two Fiber Braid, Internal Nylon Barrier - (R12 & R134A Compatible) - 5/16" ID - 825ft

5/16" (6) F204 by Couplamatic | -06 Refrigerant Hose | Two Fiber Braid, Internal Nylon Barrier | R12 & R134A Compatible | 5/16" ID | 825ft

Save $1,415.33

$3,538.33

$3,538.33 - $3,538.33

$3,538.33

$2,123.00

$2,123.00 - $2,123.00

$2,123.00

Couplamatic Systems Inc.
Two Fiber Braid - F204 Refrigerant Hose (R12 & R134A Compatible)

Package Quantity: 825 FT

Specifications for Variant SKU: 5/16" (6) F204 Couplamatic \| 825 \|
Series:	F204 Series
Hose Color(s):	Black
Internal Diameter:	0.3125in
Outer Diameter:	0.75in
Cover Construction:	Rubber
Applicable Specs & Approvals:	Refrigerant R12 Compatible, Refrigerant R134A Compatible

Refrigerant Hose — R12 / R134a

F204 Refrigerant Hose with Internal Nylon Barrier

Two fiber braid refrigerant hose with an internal nylon barrier that holds refrigerant in the line — compatible with both R12 and R134a mobile air conditioning systems.

1

What is this hose used for?

Air Conditioning
Refrigerant

2

What are the key specifications?

Cover

Rubber

Reinforcement

Two Fiber Braid, Internal Nylon Barrier

Temperature

-22°F to +257°F (-30°C to +125°C)

Size Range

5/16" (-06) to 5/8" (-12)

3

What are the main product features?

Internal nylon barrier — dramatically reduces refrigerant permeation through the hose wall.
R12 and R134a compatible — one hose covers both refrigerants.
Two fiber braids — flexible enough for tight engine bay routing.
-22°F to +257°F — covers under-hood temperature extremes.

4

Which sizes are available?

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Coil Footage
5/16" (6) F204	5/16"(-06)	0.750"	500 lbs.	2,000 lbs.	4"	20 lbs.	825ft
13/32" (-8) F204	13/32"(-08)	0.910"	500 lbs.	2,000 lbs.	5"	28 lbs.	725ft
1/2" (-10) F204	1/2"(-10)	1.000"	500 lbs.	2,000 lbs.	5"	33 lbs.	700ft
5/8" (-12) F204	5/8"(-12)	1.130"	350 lbs.	1,750 lbs.	6"	38 lbs.	525ft

i

Sold as bulk hose by the reel or coil. Reel and coil footage for each size is listed in the size chart above; cut lengths and hose assemblies are available — contact us for pricing.

Couplamatic Systems Inc

In the business for over 50 years, we're here to bring you the highest quality, most rigorously tested, American made hydraulic components on the market. We utilize state-of-the-art facilities and equipment to produce industry leading, quality hydraulic products. When you buy Couplamatic System Inc. products, you are buying precision and reliability.
