5/8" DH16 Couplamatic DURA-HYD Abrasion Resistant Extra Hi-Pressure Hydraulic Hose (SAE 100R16/2SC) - 5/8" ID - 250ft

5/8" DH16 by Couplamatic | DURA-HYD Abrasion Resistant | Extra Hi-Pressure Hydraulic Hose | SAE 100R16/2SC | 5/8" ID | 250ft

Save $563.55

$1,408.88

$1,408.88 - $1,408.88

$1,408.88

$845.33

$845.33 - $845.33

$845.33

Couplamatic Systems Inc.
Two Wire Braid Hoses - DH16 DURA-HYD Abrasion Resistant Extra Hi-Pressure Hydraulic Hose -(SAE 100R16/2SC)

Package Quantity: 250 FT

Specifications for Variant SKU: 5/8" DH16 Couplamatic \| 250 \|
Series:	DH16 Series
Hose Color(s):	Black
Dash Size:	-10
Internal Diameter:	0.625in
Outer Diameter:	0.937in
Applicable Specs & Approvals:	Applicable MSHA Standards, SAE 100R16
Compatible with the following Series:	Vari-Crimp Series \| A Series \| Grip Crimp Series

SAE 100R16/2SC — Abrasion Resistant

Dura-Hyd Abrasion Resistant Extra Hi-Pressure Hydraulic Hose

Two-wire SAE 100R16/2SC hose with an extra abrasion resistant flame resistant cover — a step up in cover life over standard R16 without moving to the bi-layer EX construction.

1

What is this hose used for?

High Pressure Hydraulics
Industrial
Agricultural

2

What are the key specifications?

SAE Rating

SAE 100R16/2SC

Cover

Flame Resistant, Extra Abrasion Resistant, MSHA approved.

Reinforcement

Two Wire Braids

Temperature

-40°F to +212°F (-40°C to +100°C)

3

What are the main product features?

Extra abrasion resistant cover — longer cover life than standard 100R16.
Flame resistant, MSHA approved — suitable for mining service.
Two wire braids — full SAE 100R16 / DIN 2SC working pressures.
Compact outside diameter — routes like standard R16 hose.

4

Which sizes are available?

Part Number	Hose ID	Hose OD	Working Pressure (lbs)	Min. Burst Pressure (lbs)	Min. Bend Radius	Weight per 100ft	Reel Footage
1/4" DH16	1/4"	0.530"	5,800 lbs.	23,200 lbs.	2"	18 lbs.	500ft
3/8" DH16	3/8"	0.687"	5,000 lbs.	20,000 lbs.	2.5"	27 lbs.	400ft
1/2" DH16	1/2"	0.812"	4,250 lbs.	17,000 lbs.	3.5"	35 lbs.	300ft
5/8" DH16	5/8"	0.937"	3,625 lbs.	14,500 lbs.	4"	40 lbs.	250ft
3/4" DH16	3/4"	1.090"	3,125 lbs.	12,500 lbs.	4.8"	54 lbs.	250ft
1" DH16	1"	1.405"	2,500 lbs.	10,000 lbs.	6"	74 lbs.	200ft

i

Sold as bulk hose by the reel or coil. Reel and coil footage for each size is listed in the size chart above; cut lengths and hose assemblies are available — contact us for pricing.
