60342000 (20AS) by PT-Coupling | Cam & Groove Adapter | Type AS | 2" Adapter x 2" Female NPSH | Aluminum | Buna Fuel Resistant Seal

Save $18.24

$49.12

$49.12 - $49.12

$49.12

$30.88

$30.88 - $30.88

$30.88

PT Coupling
Cam & Groove (Camlock) Adapter | Type AS | Adapter x Female NPSH | Aluminum | Buna Fuel Resistant Seal

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA

Specifications for Variant SKU: 60342000 PT-Coupling
Shape (Orientation):	Straight
Cam Type:	Type A
Ends Configuration:	2in Male Cam & Groove, 2in Female NPSH
Material(s):	Aluminum
Seal Material(s):	Buna-N/Nitrile

Features & Applications:
Female straight pipe threads are compatible with male NPSH, NPSM and NPT threads. Comes standard with a Buna Fuel Resistant straight thread gasket. Lightweight and economical. Good abrasion resistance. Fair corrosion and chemical resistance. Use with water, hydraulic oil, coolants, gasoline, and petroleum products. Made in the USA


Part Name	Item #	Adapter Size	Female NPSH Thread	Overall Length (C)	Inside Diameter (E)	Across Corners (F)	Chain Lug Extension (G)	Max. Allowable Working Press. (PSI)*
10AS	60341000	1"	1"	-	-	-	-	250 PSI
15AS	60341500	1-1/2"	1-1/2"	2.29"	1.35"	2.44"	0.33"	250 PSI
20AS	60342000	2"	2"	2.54"	1.72"	2.92"	0.31"	250 PSI
30AS	60343000	3"	3"	2.84"	2.80"	4.22"	0.44"	200 PSI
40AS	60344000	4"	4"	3.16"	3.78"	5.41"	0.39"	150 PSI
50AS	60345000	5"	5"	3.22"	4.79"	6.49"	0.35"	75 PSI
60AS	60346000	6"	6"	3.35"	5.90"	7.70"	0.60"	75 PSI

*Above maximum allowable working pressures are based on operating temperatures less than 100°F.

PT-Coupling

PT Coupling is a renowned manufacturer of Cam & Groove fittings, Punch-Lok banding, and clamps for industrial hoses. Established in 1951, the company offers a range of products made from different materials and is known for their innovative proprietary Punch-Lok design. PT Coupling's products are trusted by customers worldwide in various industries, such as agriculture, construction, and mining. With a commitment to quality and customer service, PT Coupling continues to be a leading producer of industrial hose fittings.
