60346000 (60AS) by PT-Coupling | Cam & Groove Adapter | Type AS | 6" Adapter x 6" Female NPSH | Aluminum | Buna Fuel Resistant Seal

60346000 (60AS) by PT-Coupling | Cam & Groove Adapter | Type AS | 6" Adapter x 6" Female NPSH | Aluminum | Buna Fuel Resistant Seal

Save $61.33 Save $61.33
$165.22
$165.22 - $165.22
$165.22
$103.89
$103.89 - $103.89
$103.89

PT Coupling
Cam & Groove (Camlock) Adapter | Type AS | Adapter x Female NPSH | Aluminum | Buna Fuel Resistant Seal

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA
Specifications for Variant SKU: 60346000 PT-Coupling
Shape (Orientation): Straight
Cam Type: Type A
Ends Configuration: 6in Male Cam & Groove, 6in Female NPSH
Material(s): Aluminum
Seal Material(s): Buna-N/Nitrile
Features & Applications:
  • Female straight pipe threads are compatible with male NPSH, NPSM and NPT threads.
  • Comes standard with a Buna Fuel Resistant straight thread gasket.
  • Lightweight and economical. Good abrasion resistance. Fair corrosion and chemical resistance.
  • Use with water, hydraulic oil, coolants, gasoline, and petroleum products.
  • Made in the USA
Part
Name		 Item # Adapter
Size		 Female NPSH
Thread		 Overall
Length
(C)		 Inside
Diameter
(E)		 Across
Corners
(F)		 Chain Lug
Extension
(G)		 Max. Allowable
Working Press.
(PSI)*
10AS 60341000 1" 1" - - - - 250 PSI
15AS 60341500 1-1/2" 1-1/2" 2.29" 1.35" 2.44" 0.33" 250 PSI
20AS 60342000 2" 2" 2.54" 1.72" 2.92" 0.31" 250 PSI
30AS 60343000 3" 3" 2.84" 2.80" 4.22" 0.44" 200 PSI
40AS 60344000 4" 4" 3.16" 3.78" 5.41" 0.39" 150 PSI
50AS 60345000 5" 5" 3.22" 4.79" 6.49" 0.35" 75 PSI
60AS 60346000 6" 6" 3.35" 5.90" 7.70" 0.60" 75 PSI

*Above maximum allowable working pressures are based on operating temperatures less than 100°F.

PT-Coupling

PT Coupling is a renowned manufacturer of Cam & Groove fittings, Punch-Lok banding, and clamps for industrial hoses. Established in 1951, the company offers a range of products made from different materials and is known for their innovative proprietary Punch-Lok design. PT Coupling's products are trusted by customers worldwide in various industries, such as agriculture, construction, and mining. With a commitment to quality and customer service, PT Coupling continues to be a leading producer of industrial hose fittings.
