60800041 (40VL) by PT-Coupling | Cam & Groove Dust Cap | with Locking Cam Arms | Type VL | 4" Coupler | Aluminum XLS

Save $37.52

$101.08

$101.08 - $101.08

$101.08

$63.56

$63.56 - $63.56

$63.56

PT Coupling
Cam and Groove (Camlock) Dust Cap with Locking Cam Arms | Type VL | Aluminum XLS

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA

Specifications for Variant SKU: 60800041 PT-Coupling
Shape (Orientation):	Straight
Cam Type:	Type DC
Ends Configuration:	4in Female Cam & Groove
Material(s):	Aluminum

Overview:
PT Quick Connect/Disconnect Couplings provide for quick connecting and disconnecting by means of the camming action. This camming action allows pipe and hose connections to be made without the need of hand tools or difficult threaded connections. Cam and groove couplings are made up of two parts, male (adapter/plug) and female (coupler/socket) that work together. The male adapter is simply inserted into the female coupler until contact is made with the gasket. Both cam arms on the coupler are then pressed down/closed simultaneously to produce a uniform gasket compression between the seal surfaces. This seal is created because the cam arms of the female coupler fit snugly against the groove of the male adapter. A positive seal requires that the surfaces on the gasket seat, the adapter face, and the gasket are smooth and uncontaminated. Also cam arms must be in the full closed position for proper locking of the coupling. To disconnect both arms must be lifted / opened simultaneously to release the seal and release the connection.
Features & Applications:
Chain Lug diameter is .25" or greater. Lightweight and economical. Good abrasion resistance. Fair corrosion and chemical resistance. Use with water, hydraulic oil, coolants, gasoline, and petroleum products. Couplings not interchangeable in the industry are sizes 8" through 12". Made in the USA


Part Name	Item #	Coupler Size	O. D. with Cam Arms Extended (A)	Outside Diameter (B)	Overall Length (C)	Chain Lug Extension (G)	Engagement Length	Max. Allowable Working Press. (PSI)*
40VL	60800041	4"	10.66"	6.56"	2.34"	0.99"	1.87"	150 PSI

*Above maximum allowable working pressures are based on operating temperatures less than 100°F.
