64541000 (PF10C) by PT-Coupling | Cam & Groove Adapter | Type PFC | 1" Coupler x 1" 150# Pipe Flange | 316 Stainless Steel

Name: 64541000 (PF10C) by PT-Coupling | Cam & Groove Adapter | Type PFC | 1" Coupler x 1" 150# Pipe Flange | 316 Stainless Steel
Brand: PT-Coupling
SKU: 64541000 PT-Coupling
Price: 136.48 USD
Availability: InStock

Save $80.57

$217.05

$217.05 - $217.05

$217.05

$136.48

$136.48 - $136.48

$136.48

PT Coupling
Cam & Groove (Camlock) Adapter | Type PFC | Coupler x 150# Pipe Flange | 316 Stainless Steel

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA

Specifications for Variant SKU: 64541000 PT-Coupling
Shape (Orientation):	Straight
Cam Type:	Other
Ends Configuration:	1in Female Cam & Groove, 1in 150# Flange
Material(s):	316 Stainless Steel

Features & Applications:
Excellent corrosion-resistant material that provides high strength at high temperatures, helps prevent contamination of product being transported, maintains cleanliness and retains a lustrous appearance. Harder than brass. Ideal for use with salt water, waste water, and many chemicals; can also be used with hydraulic oil and coolants. Pipe Flange bolt pattern conforms to ANSI B16.5 Class 150. Stainless Steel and Carbon Steel Flanges are raised face. Other materials are supplied with flat face flanges. Made in the USA


Part Name	Item #	Coupler Size	Flange Size	O. D. with Cam Arms Extended (A)	Overall Length (C)	Inside Diameter (E)	Outside Diameter (F)	Bolt Hole Diameter (J)	Number of Holes (K)	Bolt Circle Diameter (L)	Max. Allowable Working Press. (PSI)*
PF10C	64541000	1"	1"	5.04"	3.48"	0.69"	4.25"	0.63"	4	3.13"	250 PSI
PF15C	64541500	1-1/2"	1-1/2"	7.16"	5.25"	1.35"	5.00"	0.63"	4	3.88"	250 PSI
PF20C	64542000	2"	2"	7.54"	5.82"	1.63"	6.00"	0.75"	4	4.75"	250 PSI
PF25C	64542500**	2-1/2"	2-1/2"	8.03"	5.09"	2.38"	7.00"	0.75"	4	5.50"	200 PSI
PF30C	64543000	3"	3"	9.56"	5.82"	2.90"	7.50"	0.75"	4	6.00"	200 PSI
PF40C	64544000	4"	4"	10.66"	5.39"	3.60"	9.00"	0.75"	8	7.50"	150 PSI
PF60C	64546000	6"	6"	16.76"	7.75"	5.60"	11.00"	0.88"	8	9.50"	75 PSI
PF80C	64548000	8"	8"	18.73"	7.64"	7.53"	13.50"	0.88"	8	11.75"	50 PSI
PF100C	64549000	10"	10"	23.00"	8.50"	9.40"	16.00"	1.00"	12	14.25"	50 PSI

** Denotes that these parts are made as a welded fabrication.
*Above maximum allowable working pressures are based on operating temperatures less than 100°F.
