64622002 (20DWS) by PT-Coupling | Cam & Groove Adapter | Type DWS | 2" Coupler x Socket Weld for Pipe | 316 Stainless Steel

Name: 64622002 (20DWS) by PT-Coupling | Cam & Groove Adapter | Type DWS | 2" Coupler x Socket Weld for Pipe | 316 Stainless Steel
Brand: PT-Coupling
SKU: 64622002 PT-Coupling
Price: 105.11 USD
Availability: InStock

Save $62.04

$167.15

$167.15 - $167.15

$167.15

$105.11

$105.11 - $105.11

$105.11

PT Coupling
Cam & Groove (Camlock) Adapter | Type DWS | Coupler x Socket Weld for Pipe | 316 Stainless Steel

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA

Specifications for Variant SKU: 64622002 PT-Coupling
Shape (Orientation):	Straight
Cam Type:	Other
Ends Configuration:	2in Female Cam & Groove, 2in Weld End
Material(s):	316 Stainless Steel

Features & Applications:
Excellent corrosion-resistant material that provides high strength at high temperatures, helps prevent contamination of product being transported, maintains cleanliness and retains a lustrous appearance. Harder than brass. Ideal for use with salt water, waste water, and many chemicals; can also be used with hydraulic oil and coolants. Made in the USA


Part Name	Item #	Size	O. D. with Cam Arms Extended (A)	Outside Diameter (B)	Inside Diameter (C)	Overall Length (D)	Socket Depth (E)	Socket Diameter (F)	Max. Allowable Working Press. (PSI)*
10DWS	64621002	1"	5.10"	2.44"	0.97"	2.50"	0.50"	1.36"	250 PSI
12DWS	64621201	1-1/4"	6.86"	3.26"	1.25"	2.70"	0.50"	1.71"	250 PSI
15DWS	64621502	1-1/2"	7.16"	3.56"	1.50"	2.81"	0.50"	1.95"	250 PSI
20DWS	64622002	2"	7.54"	3.94"	1.88"	3.10"	0.70"	2.44"	250 PSI
30DWS	64623001	3"	9.56"	5.46"	2.88"	3.50"	.70"	3.57"	200 PSI
40DWS	64624003	4"	10.66"	6.56"	3.60"	3.90"	.70"	4.58"	150 PSI
50DWS	64625001	5"	11.67"	7.57"	4.50"	4.20"	.90"	5.66"	75 PSI
60DWS	64626004	6"	16.26"	10.16"	5.50"	4.54"	.90"	6.72"	75 PSI

*Above maximum allowable working pressures are based on operating temperatures less than 100°F.

PT-Coupling

PT Coupling is a renowned manufacturer of Cam & Groove fittings, Punch-Lok banding, and clamps for industrial hoses. Established in 1951, the company offers a range of products made from different materials and is known for their innovative proprietary Punch-Lok design. PT Coupling's products are trusted by customers worldwide in various industries, such as agriculture, construction, and mining. With a commitment to quality and customer service, PT Coupling continues to be a leading producer of industrial hose fittings.
