68544000 (PF40C) by PT-Coupling | Cam & Groove Adapter | Type PFC | 4" Coupler x 4" 150# Pipe Flange | Ductile Iron

68544000 (PF40C) by PT-Coupling | Cam & Groove Adapter | Type PFC | 4" Coupler x 4" 150# Pipe Flange | Ductile Iron

Save $175.08 Save $175.08
$471.65
$471.65 - $471.65
$471.65
$296.57
$296.57 - $296.57
$296.57

PT Coupling
Cam & Groove (Camlock) Adapter | Type PFC | Coupler x 150# Pipe Flange | Ductile Iron

Use with water, hydraulic oil, coolants, gasoline, and petroleum products.

Made in the USA
Specifications for Variant SKU: 68544000 PT-Coupling
Shape (Orientation): Straight
Cam Type: Other
Ends Configuration: 4in Female Cam & Groove, 4in 150# Flange
Material(s): Ductile Iron
Features & Applications:
  • Excellent abrasion and wear resistance. Good strength and toughness characteristics.
  • Ideal for use with sand, grout, cement, and other abrasives.
  • Pipe Flange bolt pattern conforms to ANSI B16.5 Class 150.
  • Stainless Steel and Carbon Steel Flanges are raised face. Other materials are supplied with flat face flanges.
  • Made in the USA
Part
Name		 Item # Coupler
Size		 Flange
Size		 O. D. with
Cam Arms
Extended
(A)		 Overall
Length
(C)		 Inside
Diameter
(E)		 Outside
Diameter
(F)		 Bolt Hole
Diameter
(J)		 Number
of Holes
(K)		 Bolt Circle
Diameter
(L)		 Max. Allowable
Working Press.
(PSI)*
PF30C 68543000 3" 3" 9.56" 5.82" 2.90" 7.50" 0.75" 4 6.00" 200 PSI
PF40C 68544000 4" 4" 10.66" 5.39" 3.60" 9.00" 0.75" 8 7.50" 150 PSI

*Above maximum allowable working pressures are based on operating temperatures less than 100°F.
