68BJBD-2G by Parker | Prestolok PLP Composite Push-to-Connect Fittings | Modular Fitting | 1/8" Male BSPP Double Banjo Bolt | 13mm Hex | 31.0mm Height (H) | Brass | Pack of 10

Save $15.27

$104.60

$104.60 - $104.60

$104.60

$89.33

$89.33 - $89.33

$89.33

by Parker Hannifin
Push-to-Connect Fittings:68BJBD Double Banjo Bolt

Package Quantity: 10 Units

Specifications for Variant SKU: 68BJBD-2G Parker \| 10 \|
Series:	68BJBD Series
Shape (Orientation):	Banjo
Material(s):	Brass
Special Properties:	Corrosion Resistance, Chemical Resistance, Silicone Free

Product Features:	Stainless steel grab ring Glass-reinforced nylon 6.6 body Nitrile D-seal Nylon release button Corrosion and chemical resistance NPT, BSPT, BSPP, and metric threads Silicone Free
Markets:	Pneumatic Industrial Robotic Automation Printing Packaging Textile
Compatible Media:	Compressed Air Inert Gases Vacuum
Pressure Range:	Up to 290 PSI (19.9 bar) depending on tubing Up to 260 PSI (17.9 bar) depending on tubing (3/16” size only)
Temperature Range:	-4° to +175° F (-20° to +79.4° C) 5° to +155° F (-15° to +68.3° C) (3/16” size only)
Vacuum Rating:	28" Hg
Compatible Tubing:	Semi-rigid nylon Polyurethane 95 Durometer Shore A* Nylon Fluoropolymer Polyethylene


Part Number	BSPP / M5	Hex (C)	H	H1	H2
68BJBD-M5*	M5X0.8	-	24.5 mm	7.5 mm	18.5 mm
68BJBD-2G	1/8"	13 mm	31.0 mm	7.5 mm	22.0 mm
68BJBD-4G	1/4"	17 mm	39.0 mm	9.5 mm	27.5 mm
68BJBD-6G	3/8"	20 mm	46.0 mm	11.0 mm	32.5 mm
