75710E-390 Weatherhead by Danfoss | 757 'E' Series | Male SAE 45° Flare Rigid Crimp Fitting | -10 Male SAE 45° Flare x -08 Hose Barb | Steel
75710E-390 Weatherhead by Danfoss | 757 'E' Series | Male SAE 45° Flare Rigid Crimp Fitting | -10 Male SAE 45° Flare x -08 Hose Barb | Steel
75710E-390 Weatherhead by Danfoss | 757 'E' Series | Male SAE 45° Flare Rigid Crimp Fitting | -10 Male SAE 45° Flare x -08 Hose Barb | Steel
75710E-390 Weatherhead by Danfoss | 757 'E' Series | Male SAE 45° Flare Rigid Crimp Fitting | -10 Male SAE 45° Flare x -08 Hose Barb | Steel

75710E-390 Weatherhead by Danfoss | 757 'E' Series | Male SAE 45° Flare Rigid Crimp Fitting | -10 Male SAE 45° Flare x -08 Hose Barb | Steel

$48.38 - $48.38
$48.38
$48.38 - $48.38
$48.38

Weatherhead by Danfoss
Coll-O-Crimp 757 'E' Series Crimp Fitting - Male SAE 45° Flare Rigid - Straight
Specifications for Variant SKU: 75710E-390 Danfoss
Brand: Weatherhead
Series: 757 'E' Series
Shape (Orientation): Straight
Ends Configuration: 5/8in Male SAE 45 Flare, 1/2in Hose Barb
Material(s): Steel
Compatible with the following Series: H757 Series
Applications:
  • Used with R134a and R12 applications.
  • Ideal for heavy duty truck use as well as industrial and automotive applications.
Pressure:
  • Determined by hose burst pressure.
Material:
  • Carbon steel
  • Plating: Zinc; clear trivalent chromate
Compatible Hose:
  • H757
Steel
Part Number		 Hose I.D. Tube Size Thread Size Length
A		 Drop
B		 Hose Cut-Off
Factor		 Hex
F
75710E-390 1/2" 5/8" 7/8-14 4.21" 1.56" 3.00" 7/8"

Note: Drawings may differ from actual parts.
