7808 04 11 by Parker | Pneumatic Threshold Sensor | 1/8" Male NPT Thread x 1/8" Female NPT Thread | 9/16" Hex | 2.06" Length | Straight | Nylon

Save $11.31

$53.35

$53.35 - $53.35

$53.35

$42.04

$42.04 - $42.04

$42.04

by Parker Hannifin
Threshold Sensor Fittings:7808 - pneumatic threshold sensor 5/32 tube pilot/signal ports to NPT or UNF

Specifications for Variant SKU: 7808 04 11 Parker
Series:	7808 Series
Shape (Orientation):	Straight
Material(s):	Brass, Glass-Reinforced Nylon
Seal Material(s):	Buna-N/Nitrile Rubber
Special Properties:	Valved

Product Features:	Glass-reinforced nylon 6.6 body Brass screw NBR seal Silicone-Free
Markets:	Factory/Process Automation Packaging Pneumatics Semi-Conductor
Applications:	Robotics Packaging Textile Machine Tools Pneumatic Systems
Pressure Range	43.5 to 116 psi (3 to 8 bar)
Temperature Range	5° to 140° F (-15° to 60° C)
Back Pressure	08.5 psi to 1 bar
Response Time	3 ms
Compatible Tubing:	Semi-Rigid Nylon Polyurethane 95 Durometer Shore A Fluoropolymer


Part Number	NPT / UNF(C)	orifice	F	H	J	L	Oz
7818 04 20*	10-32	.08	5/16"	.62"	.43"	1.70"	.88 Oz
7808 04 11	1/8"	.20	9/16"	.90"	.62"	1.74"	1.55 Oz
7808 04 14	1/4"	.27	5/8"	1.09"	.76"	1.81"	2.51 Oz
7808 04 18	3/8"	.39	7/8"	1.13"	.92"	1.91"	3.25 Oz

*10-32: bolt zinc passivated steel
