7808 04 14 by Parker | Pneumatic Threshold Sensor | 1/4" Male NPT Thread x 1/4" Female NPT Thread | 5/8" Hex | 2.19" Length | Straight | Nylon

Save $4.41

$48.47

$48.47 - $48.47

$48.47

$44.06

$44.06 - $44.06

$44.06

by Parker Hannifin
Threshold Sensor Fittings:7808 - pneumatic threshold sensor 5/32 tube pilot/signal ports to NPT or UNF

Quantity

More payment options

Can I get a discount on my purchase?

Our listed prices are our lowest possible price with current costing but when volumes/value are high enough sometimes we can pass on a discount from the manufacturer.

Some products have predefined quantity discounts that will apply automatically, those pages have a table near the price describing the discount teirs.

If you feel your purchase quantity of a particular product is very large and want us to investigate with the manufacturer please feel free to Contact Us.

What if my item is out of stock?

All customers get an email regarding the shipping time frame of their purchase, usually within the business day. If your item is in stock we will ship within 1 business day, otherwise, the email will contain a lead time. If you do not receive this email, we recommend checking your email's spam folder. If you have any questions at that point please do not hesitate to Contact Us or chat below!

Can I get free shipping?

Shipping will calculate as free instantly if your order value exceeds $5000.

Some exceptions apply.

Free Freight is only available for the Contiguous USA.

Specifications for Variant SKU: 7808 04 14 Parker
Series:	7808 Series
Shape (Orientation):	Straight
Material(s):	Brass, Glass-Reinforced Nylon
Seal Material(s):	Buna-N/Nitrile Rubber
Special Properties:	Valved

Product Features:	Glass-reinforced nylon 6.6 body Brass screw NBR seal Silicone-Free
Markets:	Factory/Process Automation Packaging Pneumatics Semi-Conductor
Applications:	Robotics Packaging Textile Machine Tools Pneumatic Systems
Pressure Range	43.5 to 116 psi (3 to 8 bar)
Temperature Range	5° to 140° F (-15° to 60° C)
Back Pressure	08.5 psi to 1 bar
Response Time	3 ms
Compatible Tubing:	Semi-Rigid Nylon Polyurethane 95 Durometer Shore A Fluoropolymer


Part Number	NPT / UNF(C)	orifice	F	H	J	L	Oz
7818 04 20*	10-32	.08	5/16"	.62"	.43"	1.70"	.88 Oz
7808 04 11	1/8"	.20	9/16"	.90"	.62"	1.74"	1.55 Oz
7808 04 14	1/4"	.27	5/8"	1.09"	.76"	1.81"	2.51 Oz
7808 04 18	3/8"	.39	7/8"	1.13"	.92"	1.91"	3.25 Oz
7808 04 22	1/2"	.55	1"	1.17"	1.23"	2.05"	5.47 Oz

*10-32: bolt zinc passivated steel
