940406LF by Midland | Lead Free Copper Press Ball Valve | 1-1/4" Press End x 1-1/4" Press End | Brass

Save $1.19 Save $1.19
Original price $48.76
Original price $48.76 - Original price $48.76
Original price $48.76
Current price $47.57
$47.57 - $47.57
Current price $47.57

Midland Industries
Lead Free Copper Press Ball Valve - Press End x Press End - Brass

Midland Series "940 LF" 2-Piece, Full Port, Lead Free, Copper, Press Ball Valves are designed for use in flameless, copper press piping systems.

Features a lead free brass body, adjustable packing gland and blowout proof stem with stem a single O-ring seal.

Comes with integral ASTM-B88 compliant press end connections that can be used with type K, L, M, hard copper tubing 1/2" - 4" utilizing industry standard tools.

This product will take 2-3 Weeks minimum to ship.

Inventory @ Manufacturers Warehouse: 174 Units

Can I get a discount on my purchase?

Our listed prices are our lowest possible price with current costing but when volumes/value are high enough sometimes we can pass on a discount from the manufacturer.

Some products have predefined quantity discounts that will apply automatically, those pages have a table near the price describing the discount teirs.

If you feel your purchase quantity of a particular product is very large and want us to investigate with the manufacturer please feel free to Contact Us.

What if my item is out of stock?

All customers get an email regarding the shipping time frame of their purchase, usually within the business day. If your item is in stock we will ship within 1 business day, otherwise, the email will contain a lead time. If you do not receive this email, we recommend checking your email's spam folder. If you have any questions at that point please do not hesitate to Contact Us or chat below!

Can I get free shipping?

Shipping will calculate as free instantly if your order value exceeds $5000.

Some exceptions apply.

Free Freight is only available for the Contiguous USA.

Specifications for Variant SKU: 940406LF Midland
Shape (Orientation): Straight
Ends Configuration: 1-1/4in Push-to-Connect, 1-1/4in Push-to-Connect, Some Ends Match
Material(s): Lead Free Brass
Seal Material(s): NBR
Applicable Specs & Approvals: UPC, NSF 61, AB1953, NSF 372, Lead Free as per the Safe Drinking Water Act
Special Properties: Lead Free
Features:
  • Integral press end connections designed for hard and soft copper tubing
  • 250 WOG - 250 CWP (2-1/2" - 4")
  • One O-Ring design
  • Blow Out Proof Stem
  • Lead Free Lead Free Info (PDF)
Construction:
  • Full Port Stainless Steel ball
Specifications:
  • ISO-9001
  • UPC & NSF-61 Compliant
  • AB1953 & NSF-372 Compliant
About Midland Press Ball Valves:
  • Midland Copper Press Ball Valves are a heat-free method for joining copper tubes. Midland's press valve allows installers the confidence to know the joint is secure due to the leak-detection o-ring. During low pressure testing, if the joint is not pressed properly, the specialized o-ring will leak. This allows the installer to correct the press before the system is operational at higher pressures.
Part Name Material
Body Lead Free Brass
Seat PTFE
Ball Stainless Steel
Stem O-Ring NBR
Packing Nut Brass
Stem Brass (1/2" - 2")
Stainless Steel(2-1/2" - 4")
Lock Nut Ferrum /Zinc Plated
Lock Washer Ferrum /Zinc Plated
Packing PTFE
Handle Ferrum /Chrome Plated
Cap Lead Free Brass
Body O-Ring NBR
Press O-Ring EPDM
Part Number Size D L H W CV
940403LF
1/2" 0.591" 3.46" 1.81" 3.15" 18.55
940404LF
3/4" 0.748" 4.29" 2.09" 3.60" 29.76
940405LF
1" 0.984" 4.29" 2.25" 3.92" 51.55
940406LF
1-1/4" 1.259" 5.63" 2.52" 4.41" 84.42
940407LF
1-1/2" 1.574" 5.63" 2.74" 5.35" 131.93
940408LF
2" 1.941" 5.63" 3.03" 6.79" 200.35
940409LF
2-1/2" 2.520" 7.76" 4.25" 7.46" 338.43
940410LF
3" 2.874" 8.19" 4.58" 8.17" 445.44
940411LF
4" 3.839" 9.25" 5.49" 9.88" 783.88
Midland Industries

Midland Industries

Midland Industries is a family of brands recognizable industry wide. Midland is a supplier of brass fittings, valves, and accessories for hose, pipe and tube in brass, bronze, stainless steel, steel, malleable iron, and plastics.
