FC5098-0404S Aeroquip by Danfoss | Female SAE 45° Swivel 90° Elbow PTFE Crimp Fitting | FC Series | Complete Fitting | -04 Female SAE 45° Swivel x -04 Hose Barb | Steel | Pack of 10

Minimum Order Quantity: 10 Units

$268.00 - $268.00

$268.00

$268.00 - $268.00

$268.00

PTFE Crimp Fittings

SAE Swivel Elbow Fittings - Steel

Specifications for Variant SKU: FC5098-0404S Danfoss \| 10 \|
Shape (Orientation):	90 Degree
Ends Configuration:	1/4in Female SAE 45 Flare, 1/4in Hose Barb
Material(s):	Steel
Special Properties:	Swivel
Compatible with the following Series:	2807 \| FC465 \| S-TW \| SC-TW

Aeroquip® by Danfoss
Teflon* PTFE Crimp Fitting - Female SAE 45° Swivel - 90° Elbow - Steel

FC Series

(Formerly Eaton Aeroquip)

Technical Info:
Crimp Fitting Socket Data.PDF


	Component Part Numbers
Complete Fitting Part Number	Nipple Assembly Part Number	Socket Part Number	Thread	Hose Size	A	D	E&Oslash	H	Hex 1
FC5098-0404S	FC4098-0404S	FC3596-04S	7/16-20	-04	1.28"	0.69"	0.12"	0.68"	9/16"
FC7217-0606S	FC6217-0606S	FC3443-05S	5/8-18	-06	1.31"	0.82"	0.25"	0.85"	3/4"

* Teflon™ is a trademark of The Chemours Company FC, LLC used under license by Eaton.

Danfoss (Eaton - Aeroquip)

Danfoss is a global technology leader in power management solutions that make electrical, hydraulic and mechanical power operate more efficiently, reliably, safely and sustainably. Danfoss hydraulic pumps, motors, transmissions, valves, cylinders, controls, hose and fittings offer a unique combination of proven technology and innovative design that translates directly into reliable performance and enhanced uptime.
