A-SS-500 by Campbell Fittings | Standard Cobra Cam & Groove Coupling | Type A | 5" Male Adapter x 5" Female NPT Thread | 304 Stainless Steel

A-SS-500 by Campbell Fittings | Standard Cobra Cam & Groove Coupling | Type A | 5" Male Adapter x 5" Female NPT Thread | 304 Stainless Steel

Save $102.92 Save $102.92
$257.30
$257.30 - $257.30
$257.30
$154.38
$154.38 - $154.38
$154.38

by Campbell
Standard Cobra Cam & Groove Couplings:304 Stainless Steel Part A
Specifications for Variant SKU: A-SS-500 Campbell Fittings
Shape (Orientation): Straight
Cam Type: Type A
Ends Configuration: 5in Female Cam & Groove, 5in Female NPT
Material(s): 304 Stainless Steel
STANDARD COBRA:
  • Standard COBRA Cam & Groove Couplings cover a range of diameters from 3/4” thru 8”. These couplings are used at relatively low pressures (see Coupling Selection Guide) in a range of applications including both suction and discharge. The recommended hose attachment for these products can be either Strapbinder Band Clamps by Campbell or Crimpnology™ Crimp Sleeves.
Part Number NPT
A-SS-75 3/4"
A-SS-100 1"
A-SS-125 1-1/4"
A-SS-150 1-1/2"
A-SS-200 2"
A-SS-250 2-1/2"
A-SS-300 3"
A-SS-400 4"
A-SS-500 5"
A-SS-600 6"
A-SS-800 8"

Campbell Fittings

Campbell Fittings offers a range of hose fittings, couplings, ferrules, and sleeves, for applications across a variety of industries.
