BM-0402 by Campbell Fittings | Male Hose Barb Insert | 1/4" Male NPT Thread x 1/8" Hose Barb | Straight | Brass | Pack of 25

BM-0402 by Campbell Fittings | Male Hose Barb Insert | 1/4" Male NPT Thread x 1/8" Hose Barb | Straight | Brass | Pack of 25

Save $24.01 Save $24.01
$60.03
$60.03 - $60.03
$60.03
$36.02
$36.02 - $36.02
$36.02

by Campbell
Small Diameter Multi-Purpose Fittings:Barb Hose insert

Package Quantity: 25 Each

Specifications for Variant SKU: BM-0402 Campbell Fittings | 25 |
Shape (Orientation): Straight
Ends Configuration: 1/4in Male NPT, 1/8in Hose Barb
Material(s): Brass
Brass Garden Hose Couplings: Precision screw machined from brass.
Recommended use:
  • Low pressure water
Recommended hose attachment:
  • Brass Crimp-on Ferrules
  • Worm Gear Clamps
  • Preformed Band Clamps
Part Number Hose x NPT
BM-0402 1/4" x 1/8"
BM-0404 1/4" x 1/4"
BM-0406 1/4" x 3/8"
BM-0502 5/16" x 1/8"
BM-0504 5/16" x 1/4"
BM-0602 3/8" x 1/8"
BM-0604 3/8" x 1/4"
BM-0606 3/8" x 3/8"
BM-0608 3/8" x 1/2"
BM-0804 1/2" x 1/4"
BM-0806 1/2" x 3/8"
BM-0808 1/2" x 1/2"
BM-0812 1/2" x 3/4"
BM-1006 5/8" x 3/8"
BM-1008 5/8" x 1/2"
BM-1012 5/8" x 3/4"
BM-1208 3/4" x 1/2"
BM-1212 3/4" x 3/4"
BM-1612 1" x 3/4"
BM-1616 1" x 1"
BM-2016 1-1/4" x 1"
Campbell Fittings

Campbell Fittings

Campbell Fittings offers a range of hose fittings, couplings, ferrules, and sleeves, for applications across a variety of industries.
