BV2BV-02511 Dixon Valve 1/4" Two-Piece Industrial Brass Ball Valve - Female NPT x Female NPT - PTFE Seat - No Handle

BV2BV-02511 Dixon Valve 1/4" Two-Piece Industrial Brass Ball Valve - Female NPT x Female NPT - PTFE Seat - No Handle

$0.00 - $0.00
$0.00
$0.00
$0.00 - $0.00
$0.00

Dixon Sanitary Valves
Two-Piece Industrial Brass Ball Valve | Female NPT x Female NPT | PTFE Seat | No Handle
Specifications for Variant SKU: BV2BV-02511 Dixon
Shape (Orientation): Straight
Material(s): Brass
Seal Material(s): PTFE

What are the Features?

  • Full port
  • Female NPT ends
  • Blow-out proof stem
  • ISO 5211 mounting pad

How is it Constructed?

  • PTFE seats with O-ring backing
  • Double O-ring stem packing
  • ISO 5211 mounting pad

What are the Specifications?

  • Maximum Operating Pressure: 600 PSI WOG
  • Maximum Temperature: 320°F (160°C)
Part Number Size Body Seat Handle Dimensions
A B C D E F Break Torque (in. lbs.)
BV2BV-02511 1/4" Brass PTFE No Handle - 1.28" 2.64" F03 - 9mm 53 in. lbs.

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
