D-1616-FNPR Alfagomma by Kuriyama | D Series | One-Piece AlfaCrimp Hydraulic Hose Fitting | -16 Hose ID x -16 Female NPTF Rigid | Steel

Name: D-1616-FNPR Alfagomma by Kuriyama | D Series | One-Piece AlfaCrimp Hydraulic Hose Fitting | -16 Hose ID x -16 Female NPTF Rigid | Steel
Brand: Kuriyama
SKU: D-1616-FNPR Kuriyama
Price: 48.69 USD
Availability: InStock

Save $19.48

$68.17

$68.17 - $68.17

$68.17

$48.69

$48.69 - $48.69

$48.69

Kuriyama of America Inc.
Alfagomma | D Series | One-Piece AlfaCrimp Hydraulic Hose Fitting | Hose Barb x Female NPTF Rigid

Specifications for Variant SKU: D-1616-FNPR Kuriyama
Brand:	Alfagomma
Series:	D Series
Shape (Orientation):	Straight
Ends Configuration:	1in Hose Barb, 1in Female NPTF
Material(s):	Steel
Compatible with the following Series:	E4K Series \| TR1MT Series \| TR2MT Series \| TF2MT Series \| ABT3K Series \| TR1HT Series \| TR2HT Series

About D-Series Fittings:
A one-piece non-skive crimp fitting for: Wire braided hoses above 1" ID and 4 wire spiral hose. Alfabiotech 3000 1-1/4" ID thru 2" ID. Alfabiotech 4000 3/8" ID thru 1-1/4" ID.
Features:
Alfagomma Top Coat Tested in accordance with ASTM B117-03 and UNI ISO 9227 standards. Over 500 hours corrosion prevention in salt spray fog to white rust. More than 1000 hours corrosion resistance to red rust.
Material:
Steel


Part Number	Hose ID Size			F Thread		C Cut-Off Factor	CH2	Weight
Part Number	Dash Size	(in.)	(mm)	Dash Size	Size (in) - TPI	(mm)	(mm)	lbs/each
D-1212-FNPR	12	3/4"	19.0mm	12	3/4-14	38.1mm	32mm	0.58 lbs
D-1616-FNPR	16	1"	25.4mm	16	1-11-1/2	44.9mm	38mm	1.01 lbs
