Tank Truck | Single Plane Hose Swivel for Diesel and Gasoline Nozzles

Manufactured to connect to NPT threaded hose and nozzle connections.

Specifications for Variant SKU: DAWSCL2 Dixon
Brand:	Bayco
Shape (Orientation):	Multi-Directional
Material(s):	Aluminum
Seal Material(s):	Viton/FKM

Construction:
Body: Aluminum. Brass hex nut prevents galling in the nozzle. Retainer: Nylon cord. Seals: F-7036 Viton®.
Safety Note:
All fuel contains additives, which can vary by fuel brand and season. Please contact Dixon with a list of all additives and we will advise of any known compatibility issues.

Part Number	Male Adapter x Male NPT
DAWSCL15	1-1/2" x 1-1/2"
DAWSCL2	2" x 2"
