DPHDS250 by Kuriyama | SPHDS Series | Sanitary Double Pin Clamp for Tri-Clamp | 2-1/2" Fitting End Size | 2-1/2" Clamp Size | 304 Stainless Steel

Save $8.38

$24.60

$24.60 - $24.60

$24.60

$16.22

$16.22 - $16.22

$16.22

Kuriyama of America Inc.
Sanitary Double Pin Clamps | Fitting End Size x Clamp Size

Specifications for Variant SKU: DPHDS250 Kuriyama
Series:	DPHDS Series
Material(s):	304 Stainless Steel

What are the Features?

Durable 304 stainless steel.
Double pin design for more even sealing pressure.
For use with TCS-SS, RHAS-SS or BHAS-SS series fittings.
For use with adapters TCMPS-SS, TCFPS-SS, TCWL-SS, TCWS-SS.

Part Number	Fitting End Size (in)	Clamp Size (in)	Weight Each (lbs)
DPHDS150	1 & 1 1/2"	1-1/2"	0.51 lbs
DPHDS200	2"	2"	0.60 lbs
DPHDS250	2-1/2"	2-1/2"	0.64 lbs
DPHDS300	3"	3"	0.74 lbs
DPHDS400	4"	4"	1.02 lbs
