DVF-A50RB Dixon Valve KF Blank Flange for D-TORR Vacuum Fitting - Flange Size: KF50 - 316L Stainless Steel

DVF-A50RB Dixon Valve KF Blank Flange for D-TORR Vacuum Fitting - Flange Size: KF50 - 316L Stainless Steel

$0.00 - $0.00
$0.00
$0.00
$0.00 - $0.00
$0.00

Dixon Sanitary Fittings D-TORR Series Vacuum Fittings: KF Blank Flange - 316L Stainless Steel

Vacuum sealing for 1/2" - 2" OD tubing in the semiconductor industry
Specifications for Variant SKU: DVF-A50RB Dixon
Material(s): 316L Stainless Steel
Features:
  • KF assemblies contain two identical flanges and a centering ring assembly and are clamped together with a thumbscrew clamp. Coupling features prevent O-ring collapse and keep the assembly aligned.
  • KF flanges are compatible with other ISO-KF-QF vacuum flange manufacturers' components
  • All fittings are IPA cleaned and bagged in a controlled environment
Materials:
  • 316L Stainless Steel
Specifications:
  • Maximum temperature: 302°F (150°C)
  • Helium leakage testing to 1x10-8 Torr
  • Standards followed: ISO2681
Part Number Flange Size Dimensions
A B
DVF-A10RB KF10 1.18" 0.12"
DVF-A16RB KF16 1.18" 0.11"
DVF-A25RB KF25 1.58" 0.13"
DVF-A40RB KF40 2.17" 0.12"
DVF-A50RB KF50 2.95" 0.12"
