FJ3111-02-0810S E-Z Clip System by Danfoss | Female O-Ring (Long Pilot) Metric Thread 90° Elbow | A/C Refrigeration Fitting | M20 Female O-Ring Long Pilot x -10 Hose Barb | Steel

FJ3111-02-0810S E-Z Clip System by Danfoss | Female O-Ring (Long Pilot) Metric Thread 90° Elbow | A/C Refrigeration Fitting | M20 Female O-Ring Long Pilot x -10 Hose Barb | Steel | Pack of 10

$892.47 - $892.47

$892.47

$892.47 - $892.47

$892.47

Danfoss A/C & Refrigeration
E-Z Clip System - Female O-Ring (Long Pilot) Metric Thread - 90° Elbow

O-Ring Not Included. Clips & Cages Sold Separately.

For use with GH001 EverCool A/C & Refrigeration Hose.

Package Quantity: 10 Units

Specifications for Variant SKU: FJ3111-02-0810S Danfoss \| 10 \|
Brand:	E-Z Clip
Shape (Orientation):	90 Degree
Ends Configuration:	M20 Female O-Ring Long Pilot, 5/8in Hose Barb
Material(s):	Steel
Compatible with the following Series:	GH001 Series \| GH134 Series

Additional Information:
E-Z Clip Assembly Instructions & Guide.PDF


Steel Part Number	Thread "T"	Hose Size	A Ref.	D Ref.	H Ref.	Ref.	Clip & Cage Kit (Required)	O-Ring Options
Steel Part Number	Thread "T"	Hose Size	A Ref.	D Ref.	H Ref.	Ref.	Clip & Cage Kit (Required)	Neoprene	Green HNBR
FJ3111-01-0808S	M20 x 1.5	-08	3.77"	2.23"	1.62"	0.94"	FF14172	22546-13	FF90178-13
FJ3111-02-0810S	M20 x 1.5	-10	3.78"	2.23"	1.62"	0.94"	FF14173	22546-13	FF90178-13
FJ3111-03-0806S	M20 x 1.5	-06	3.75"	2.23"	1.62"	0.94"	FF14171	22546-13	FF90178-13
FJ3409-1212S	M27 x 2	-12	4.74"	3.16"	2.56"	1.25"	FF14174	22546-17	FF90178-17
