G4030-A-AL by Dixon Valve | Global Cam & Groove Reducer (Jump Size) Adapter | Type A | 4" Adapter x 3" Female NPT | A380 Permanent Mold Aluminum

G4030-A-AL by Dixon Valve | Global Cam & Groove Reducer (Jump Size) Adapter | Type A | 4" Adapter x 3" Female NPT | A380 Permanent Mold Aluminum

Save $5.87 Save $5.87
$52.83
$52.83 - $52.83
$52.83
$46.96
$46.96 - $46.96
$46.96

Dixon Valve
Global Cam & Groove | Type A | Reducer (Jump Size) Adapter | Adapter x Female NPT

Designed for use with liquids.
Specifications for Variant SKU: G4030-A-AL Dixon
Shape (Orientation): Straight
Ends Configuration: 4in Male Cam & Groove, 3in Female NPT
Material(s): Aluminum
Construction:
  • Made to Dixon specifications and branded Dixon.
Safety Notes:
  • Under no circumstances should cam and groove couplings be used for compressed air or steam service!
  • Pressure rating is based on the seal of the mating part.
  • Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70°F / 21°C with a standard seal installed.
How It Works:
  • To make a connection, simply slide the adapter into the coupler and with normal hand pressure, press the cam levers down.
  • Uncoupling is as quick and simple as coupling. Just lift the cam arms and remove the adapter.
Specifications:
  • Designed to interchange with all products produced to A-A-59326D.
A380 Permanent
Mold Aluminum
Part Number		 Adapter x Female NPT Size Max. Operating Pressure
G3020-A-AL 3" x 2" 125 PSI
G4030-A-AL 4" x 3" 100 PSI
