GJS-12 by Campbell Fittings | Ground Joint Coupling | Hose Stem | 3" Hose Size x 3" Hose Barb | Viton® Seal | Straight | Ductile Iron

Save $47.29 Save $47.29
Original price $118.22
Original price $118.22 - Original price $118.22
Original price $118.22
Current price $70.93
$70.93 - $70.93
Current price $70.93

by Campbell
VITON® Seal Ground Joint Couplings:VITON® Seal Hose Stem

Specifications for Variant SKU: GJS-12 Campbell Fittings
Shape (Orientation): Straight
Ends Configuration: 3in Male NPT, 3in Hose Barb
Material(s): Ductile Iron
Seal Material(s): Viton
Recommended Use:
  • High-pressure steam and air
Recommended Hose Attachments:
  • Interlocking Ferrules
  • Interlocking U-bolt clamps
Features and Benefits:
  • Viton Seal Coupling pass 1000 hour MIL-H-29210 steam test.
  • Eliminates leaks with nut hand tightened.
  • Viton seal (formulated by DuPont for high pressure steam and air applications) is protected inside machined stem groove and by swivel nut, extending working life.
  • Spud does not contain plastic seat, extending working life.
  • Interchangeable with old-style domestic ground joint couplings.
  • Machined hose ends with smooth end detail to reduce potential failure due to abrasion - grips, seals, and protects hose.
  • Interlock groove locks ferrule into place for superior holding power.
Part Number Hose Size
GJS-5 1-1/4"
GJS-6 1-1/2"
GJS-8 2"
GJS-10 2-1/2"
GJS-12 3"
GJS-16 4"

Campbell Fittings

Campbell Fittings offers a range of hose fittings, couplings, ferrules, and sleeves, for applications across a variety of industries.
