GLBR100-4 by Dixon Valve | Liquid Filled Gauge | Lower Mount | 4" Face | 1/2" Lower Mount | 0-100 PSI Range | Brass

Save $22.85

$241.38

$241.38 - $241.38

$241.38

$218.53

$218.53 - $218.53

$218.53

Dixon Valve
Dixon® Gauge | Liquid Filled Gauge | Lower Mount

Designed for long, reliable service under rugged conditions.

Typical applications include those on pumps, hydraulic and pneumatic systems, compressors, machine tools and many other installations where it is necessary to have a gauge with a non-corrosive movement.

Quantity

Specifications for Variant SKU: GLBR100-4 Dixon
Series:	GLBR-4 Series

Features:
± 2-1-2% accuracy on 2-1/2"; ±1% accuracy on 4". Brass movement with highly polished bearing surfaces.
Materials:
Window: acrylic with membrane assembly. Bourdon tube: copper alloy. Glycerin filled. 2-1/2" face gauges: solid cast brass case with polished ABS cover ring. 4" face gauges: cast brass, silver painted case with chrome plated brass cover ring.
Specifications:
Ambient temperature range: -4°F to 140°F (-20°C to 60°C)
Term Meanings:
Figure Interval: Figure Interval (Increments between PSI numbers on gauge face). Gradient Interval: Graduation Interval (Fractional increments between PSI numbers on gauge face).

2-1/2" Face 1/4" Lower Mount Part Number	2-1/2" Face 1/4" Center Back Mount Part Number	4" Face 1/2" Lower Mount Part Number	PSI Range	Figure Interval	Minor Gradient
GLBR15	GLBRC15	GLBR15-4	0-15 PSI	3	0.2
GLBR30	GLBRC30	GLBR30-4	0-30 PSI	5	0.5
GLBR60	GLBRC60	GLBR60-4	0-60 PSI	10	1
GLBR100	GLBRC100	GLBR100-4	0-100 PSI	10	1
GLBR160	GLBRC160	GLBR160-4	0-160 PSI	20	2
GLBR200	GLBRC200	GLBR200-4	0-200 PSI	20	2
GLBR300	GLBRC300	GLBR300-4	0-300 PSI	50	5
GLBR400	GLBRC400	GLBR400-4	0-400 PSI	50	5
GLBR600	GLBRC600	GLBR600-4	0-600 PSI	100	10
GLBR1000	GLBRC1000	GLBR1000-4	0-1000 PSI	100	10
GLBR1500	GLBRC1500	GLBR1500-4	0-1500 PSI	300	20
GLBR2000	GLBRC2000	GLBR2000-4	0-2000 PSI	200	20
GLBR3000	GLBRC3000	GLBR3000-4	0-3000 PSI	500	50
GLBR5000	GLBRC5000	GLBR5000-4	0-5000 PSI	500	50
-	-	GLBR100004	0-10000 PSI	1000	100
