IH600 by Dixon Valve | Boss-Lock Cam & Groove Dust Cap | Type H | 6" Coupler End | Plated Malleable Iron

Name: IH600 by Dixon Valve | Boss-Lock Cam & Groove Dust Cap | Type H | 6" Coupler End | Plated Malleable Iron
Brand: Dixon
SKU: IH600 Dixon
Price: 242.09 USD
Availability: InStock

Save $161.39

$403.48

$403.48 - $403.48

$403.48

$242.09

$242.09 - $242.09

$242.09

Dixon Valve
Boss-Lock Cam & Groove Fitting | Type H | Dust Cap

Prevents dust and debris from entering the hose, while protecting the coupling from damage when not in use.

Specifications for Variant SKU: IH600 Dixon
Brand:	Boss-Lock
Cam Type:	Other
Ends Configuration:	6in Female Cam & Groove
Material(s):	Plated Malleable Iron
Seal Material(s):	Buna-N/Nitrile Rubber

Construction:
Nitrile rubber gasket supplied standard. Supplied with safety clips.
Safety Notes:
Dust caps and dust plugs are not to be used in pressure applications for safety and environmental reasons. Dixon and Boss-Lock cam & groove couplings do not interchange in the 8" size.
Specifications:
Produced to interchange with all product produced to Commercial Item Description A-A-59326D.

356T6 Aluminum Part Number	Brass Part Number	Plated Malleable Iron Part Number	316 Stainless Steel Part Number	Size
-	-	-	RH75BL	3/4"
AH100	BH100	-	RH100BL	1"
AH125	BH125	-	RH125BL	1-1/4"
AH150	BH150	IH150	RH150BL	1-1/2"
AH200	BH200	IH200	RH200BL	2"
AH250	BH250	-	-	2-1/2"
AH300	BH300	IH300	RH300BL	3"
AH400	BH400	IH400	RH400BL	4"
AH600	BH600	IH600	-	6"
AH800	-	-	-	8"
